14.5.12 Measuring the AM Modulation Depth
All remote control commands specific to AM modulation depth measurements are
described here.
● Configuring and Performing the Measurement..................................................... 864
● Example: Measuring the AM Modulation Depth....................................................865
14.5.12.1 Configuring and Performing the Measurement
The following commands control the measurement.
Useful commands for AM modulation depth described elsewhere
●
CALCulate<n>:DELTamarker<m>:X on page 985
●
CALCulate<n>:DELTamarker<m>:X:RELative? on page 1000
●
CALCulate<n>:MARKer<m>:X on page 987
Remote commands exclusive to AM modulation depth measurements
CALCulate<n>:MARKer<m>:FUNCtion:MDEPth[:STATe]................................................... 864
CALCulate<n>:MARKer<m>:FUNCtion:MDEPth:SEARchsignal ONCE............................... 864
CALCulate<n>:MARKer<m>:FUNCtion:MDEPth:RESult<t>?..............................................865
CALCulate<n>:MARKer<m>:FUNCtion:MDEPth[:STATe] <State>
This command turns the AM Modulation Depth measurement on and off.
To work correctly, the measurement requires an AM modulated signal.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<State> ON | OFF | 1 | 0
*RST: 0
CALCulate<n>:MARKer<m>:FUNCtion:MDEPth:SEARchsignal ONCE
This command initiates a search for the signals required for the AM depth measure-
ment.
Note that the command does not perform a new measurement, but looks for the sig-
nals on the current trace.
Suffix:
<n>
.
Window
<m> Marker
