R&S FSV3000 Series User Manual

Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
908User Manual 1178.8520.02 ─ 01
14.7.4 Configuring Triggered and Gated Measurements
The commands required to configure a triggered or gated measurement in a remote
environment are described here.
The tasks for manual operation are described in Chapter 8.6, "Trigger and Gate Con-
figuration", on page 391.
The commands required for trigger input or output are described in Chapter 14.7.4.3,
"Configuring the Trigger Output", on page 916.
*OPC should be used after requesting data. This will hold off any subsequent changes
to the selected trigger source, until after the sweep is completed and the data is
returned.
● Configuring the Triggering Conditions...................................................................908
● Configuring Gated Measurements........................................................................ 913
● Configuring the Trigger Output..............................................................................916
14.7.4.1 Configuring the Triggering Conditions
The following commands are required to configure a triggered measurement.
TRIGger[:SEQuence]:DTIMe...........................................................................................908
TRIGger[:SEQuence]:HOLDoff[:TIME]..............................................................................908
TRIGger[:SEQuence]:IFPower:HOLDoff...........................................................................909
TRIGger[:SEQuence]:IFPower:HYSTeresis.......................................................................909
TRIGger<tp>[:SEQuence]:LEVel[:EXTernal<port>]............................................................ 910
TRIGger[:SEQuence]:LEVel:IFPower............................................................................... 910
TRIGger[:SEQuence]:LEVel:IQPower...............................................................................910
TRIGger[:SEQuence]:LEVel:VIDeo.................................................................................. 911
TRIGger[:SEQuence]:SLOPe.......................................................................................... 911
TRIGger[:SEQuence]:SOURce........................................................................................911
TRIGger[:SEQuence]:TIME:RINTerval..............................................................................912
TRIGger[:SEQuence]:DTIMe <DropoutTime>
Defines the time the input signal must stay below the trigger level before a trigger is
detected again.
Parameters:
<DropoutTime> Dropout time of the trigger.
Range: 0 s to 10.0 s
*RST: 0 s
Default unit: S
Manual operation: See " Drop-Out Time " on page 399
TRIGger[:SEQuence]:HOLDoff[:TIME] <Offset>
Defines the time offset between the trigger event and the start of the sweep.
Setting Basic Measurement Parameters
