R&S FSV3000 Series User Manual

Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
910User Manual 1178.8520.02 ─ 01
Manual operation: See " Hysteresis " on page 399
TRIGger<tp>[:SEQuence]:LEVel[:EXTernal<port>] <TriggerLevel>
This command defines the level the external signal must exceed to cause a trigger
event.
Note that the variable "Input/Output" connectors (ports 2+3) must be set for use as
input using the OUTPut<up>:TRIGger<tp>:DIRection command.
Suffix:
<tp>
.
irrelevant
<port> Selects the trigger port.
1 = trigger port 1 (TRIGGER INPUT connector on front panel)
2 = trigger port 2 (TRIGGER INPUT/OUTPUT connector on front
panel)
3 = trigger port 3 (TRIGGER3 INPUT/OUTPUT connector on
rear panel)
<port> Selects the trigger port.
1 = trigger port 1 (TRIG IN connector on rear panel)
2 = trigger port 2 (TRIG AUX connector on rear panel)
Parameters:
<TriggerLevel> Range: 0.5 V to 3.5 V
*RST: 1.4 V
Default unit: V
Example:
TRIG:LEV 2V
Manual operation: See " Trigger Level " on page 399
TRIGger[:SEQuence]:LEVel:IFPower <TriggerLevel>
This command defines the power level at the third intermediate frequency that must be
exceeded to cause a trigger event.
Note that any RF attenuation or preamplification is considered when the trigger level is
analyzed. If defined, a reference level offset is also considered.
Parameters:
<TriggerLevel> For details on available trigger levels and trigger bandwidths see
the data sheet.
*RST: -10 dBm
Default unit: DBM
Example:
TRIG:LEV:IFP -30DBM
Manual operation: See " Trigger Level " on page 399
TRIGger[:SEQuence]:LEVel:IQPower <TriggerLevel>
This command defines the magnitude the I/Q data must exceed to cause a trigger
event.
Setting Basic Measurement Parameters
