OUTPut<up>:TRIGger<tp>:DIRection.............................................................................. 917
OUTPut<up>:TRIGger<tp>:LEVel.................................................................................... 917
OUTPut<up>:TRIGger<tp>:OTYPe..................................................................................918
OUTPut:TRIGger<tp>:PULSe:IMMediate..........................................................................918
OUTPut:TRIGger<tp>:PULSe:LENGth............................................................................. 918
OUTPut<up>:TRIGger<tp>:DIRection <Direction>
This command selects the trigger direction for trigger ports that serve as an input as
well as an output.
Suffix:
<up>
.
irrelevant
<tp>
Parameters:
<Direction> INPut | OUTPut
INPut
Port works as an input.
OUTPut
Port works as an output.
*RST: INPut
Manual operation: See "Trigger 1/2" on page 356
OUTPut<up>:TRIGger<tp>:LEVel <Level>
This command defines the level of the (TTL compatible) signal generated at the trigger
output.
This command works only if you have selected a user defined output with
OUTPut<up>:TRIGger<tp>:OTYPe.
Suffix:
<up>
.
1..n
<tp> Selects the trigger port to which the output is sent.
2 = trigger port 2 (front)
3 = trigger port 3 (rear)
2 = Trigger 2 Input / Output
Parameters:
<Level> HIGH
5 V
LOW
0 V
*RST: LOW
Example:
OUTP:TRIG2:LEV HIGH
Manual operation: See " Level " on page 357
