OUTPut<up>:TRIGger<tp>:OTYPe <OutputType>
This command selects the type of signal generated at the trigger output.
Suffix:
<up>
.
1..n
<tp> Selects the trigger port to which the output is sent.
2 = trigger port 2 (front)
3 = trigger port 3 (rear)
2 = Trigger 2 Input / Output
Parameters:
<OutputType> DEVice
Sends a trigger signal when the R&S FSV/A has triggered inter-
nally.
TARMed
Sends a trigger signal when the trigger is armed and ready for
an external trigger event.
UDEFined
Sends a user defined trigger signal. For more information see
OUTPut<up>:TRIGger<tp>:LEVel.
*RST: DEVice
Manual operation: See " Output Type " on page 356
OUTPut:TRIGger<tp>:PULSe:IMMediate
This command generates a pulse at the trigger output.
Suffix:
<tp>
.
Selects the trigger port to which the output is sent.
2 = trigger port 2 (front)
3 = trigger port 3 (rear)
2 = Trigger 2 Input / Output
Usage: Event
Manual operation: See " Send Trigger " on page 357
OUTPut:TRIGger<tp>:PULSe:LENGth <Length>
This command defines the length of the pulse generated at the trigger output.
Suffix:
<tp>
.
Selects the trigger port to which the output is sent.
2 = trigger port 2 (front)
3 = trigger port 3 (rear)
2 = Trigger 2 Input / Output
Parameters:
<Length> Pulse length in seconds.
Default unit: S
