R&S FSV3000 Series - Configuring the Reference Frequency

Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
1091User Manual 1178.8520.02 ─ 01
● Customizing the Screen Layout...........................................................................1116
● Remote Commands for Language Settings........................................................ 1123
● Configuring the Network and Remote Control.....................................................1123
● Checking the System Configuration....................................................................1128
● Signal Generator Control Commands................................................................. 1134
● Using Service Functions......................................................................................1135
● Remote Commands for Synchronizing Parameters............................................1137
14.10.1 Configuring the Reference Frequency
[SENSe:]ROSCillator:LBWidth.......................................................................................1091
[SENSe:]ROSCillator:O100...........................................................................................1091
[SENSe:]ROSCillator:O640...........................................................................................1091
SOURce:EXTernal:ROSCillator:EXTernal:FREQuency.....................................................1092
[SENSe:]ROSCillator:SOURce...................................................................................... 1092
[SENSe:]ROSCillator:SOURce:EAUTo?......................................................................... 1092
[SENSe:]ROSCillator:TRANge.......................................................................................1093
[SENSe:]ROSCillator:LBWidth <Bandwidth>
Defines the loop bandwidth, that is, the speed of internal synchronization with the refer-
ence frequency. The setting requires a compromise between performance and increas-
ing phase noise.
For a variable external reference frequency with a narrow tuning range (+/- 0.5 ppm),
the loop bandwidth is fixed to 0.1 Hz and cannot be changed.
Parameters:
<Bandwidth> 0.1 Hz | 1 Hz | 3 Hz | 10 Hz | 30 Hz | 100 Hz | 300 Hz
The possible values depend on the reference source and tuning
range (see Table 12-2).
Default unit: Hz
Example:
ROSC:LBW 3
Manual operation: See "Loop Bandwidth" on page 616
[SENSe:]ROSCillator:O100 <State>
[SENSe:]ROSCillator:O640 <State>
This command turns the output of a reference signal on the corresponding connector
("Ref Output") on and off.
[SENSe:]ROSCillator:O640: Provides a 640 MHz reference signal on correspond-
ing connector.
Parameters:
<State> ON | OFF | 1 | 0
OFF | 0
Switches the reference off.
Configuring the R&S FSV/A
