R&S FSV3000 Series - Configuring the Trace Display and Retrieving Trace Data

Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
959User Manual 1178.8520.02 ─ 01
14.8.2 Configuring the Trace Display and Retrieving Trace Data
The commands required to work with traces are described here.
Commands required to export traces (and other result data) are described in Chap-
ter 14.9.5, "Storing Measurement Results", on page 1085.
● Configuring Standard Traces................................................................................ 959
● Configuring Spectrograms.................................................................................... 965
● Using Trace Mathematics..................................................................................... 972
● Retrieving Trace Results.......................................................................................974
● Formats for Returned Values: ASCII Format and Binary Format..........................977
● Importing and Exporting Traces............................................................................ 977
● Programming Example: Configuring a Spectrogram.............................................979
14.8.2.1 Configuring Standard Traces
Useful commands for trace configuration described elsewhere
●
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>:Y:SPACing
on page 907
●
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe] on page 905
Remote commands exclusive to trace configuration
DISPlay[:WINDow<n>]:TRACe<t>:MODE.........................................................................959
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>:MODE:HCONtinuous.........................960
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<undef>:PRESet.....................................961
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>[:STATe]............................................ 961
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>:SMOothing:APERture........................962
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>:SMOothing[:STATe]........................... 962
[SENSe:]AVERage<n>:COUNt........................................................................................963
[SENSe:]AVERage<n>[:STATe<t>]...................................................................................963
[SENSe:]AVERage<n>:TYPE..........................................................................................963
[SENSe:][WINDow<n>:]DETector<t>[:FUNCtion]...............................................................964
[SENSe:][WINDow<n>:]DETector<t>[:FUNCtion]:AUTO..................................................... 964
TRACe<n>:COPY..........................................................................................................965
DISPlay[:WINDow<n>]:TRACe<t>:MODE <Mode>
This command selects the trace mode. If necessary, the selected trace is also activa-
ted.
In case of max hold, min hold or average trace mode, you can set the number of single
measurements with [SENSe:]SWEep:COUNt. Note that synchronization to the end of
the measurement is possible only in single sweep mode.
Suffix:
<n>
.
Window
Analyzing Measurements (Basics)
