Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
905User Manual 1178.8520.02 ─ 01
Suffix:
<ip>
.
1 | 2
irrelevant
Parameters:
<Gain> 15 dB | 30 dB
The availability of gain levels depends on the model of the
R&S FSV/A.
For R&S FSV/A4, 7, 13, and 30 models: 15 dB and 30 dB
R&S FSV/A44 or higher: 30 dB
All other values are rounded to the nearest of these two.
Default unit: DB
Example:
INP:GAIN:STAT ON
INP:GAIN:VAL 30
Switches on 30 dB preamplification.
Manual operation: See " Preamplifier " on page 372
14.7.3.4
Scaling the Y-Axis
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]................................................................... 905
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:AUTO ONCE............................................... 905
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>:Y[:SCALe]:MODE..............................906
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:PDIVision.................................................... 906
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RPOSition................................................... 907
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>:Y:SPACing........................................907
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe] <Range>
This command defines the display range of the y-axis (for all traces).
Note that the command works only for a logarithmic scaling. You can select the scaling
with DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>:Y:SPACing.
Suffix:
<n>
.
Window
<t> irrelevant
Parameters:
<Range> Range: 1 dB to 200 dB
*RST: 100 dB
Default unit: HZ
Example:
DISP:TRAC:Y 110dB
Manual operation: See " Range " on page 374
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:AUTO ONCE
Automatic scaling of the y-axis is performed once, then switched off again (for all
traces).
Setting Basic Measurement Parameters
