Example:
CALC:LIM:ESP:PCL2:MIN -40 dBm
Sets the minimum power value of the second power class to -40
dBm.
Manual operation: See " PMin / PMax " on page 231
14.5.6.7 Configuring MSR SEM Measurements
The following commands configure MSR SEM measurements. For details see Chap-
ter 7.6.4.4, "Multi-Standard Radio (MSR) SEM Measurements", on page 216.
For manual operation see Chapter 7.6.5.5, "MSR Settings", on page 231.
[SENSe:]ESPectrum<sb>:MSR:APPLy.............................................................................815
[SENSe:]ESPectrum<sb>:MSR:BAND............................................................................. 815
[SENSe:]ESPectrum<sb>:MSR:BCATegory...................................................................... 816
[SENSe:]ESPectrum<sb>:MSR:CLASs............................................................................ 817
[SENSe:]ESPectrum<sb>:MSR:GSM:CARRier................................................................. 818
[SENSe:]ESPectrum<sb>:MSR:GSM:CPResent............................................................... 818
[SENSe:]ESPectrum<sb>:MSR:LTE:CPResent.................................................................819
[SENSe:]ESPectrum<sb>:MSR:MPOWer.........................................................................819
[SENSe:]ESPectrum<sb>:MSR:RFBWidth........................................................................820
[SENSe:]ESPectrum<sb>:MSR:APPLy
This command configures the SEM sweep list according to the MSR settings defined
by previous commands.
Suffix:
<sb>
.
1..n
Sub block in a Multi-SEM measurement
Example:
//Select the band category 1
ESP2:MSR:BCAT 1
//Set the base station class to medium range
ESP2:MSR:CLAS MED
//Set the maximum output power to 10 dBm.
ESP2:MSR:MPOW 10
//Set the frequency range of the base station to > 3 GHz
ESP2:MSR:BAND:HIGH
//Set the base station RF bandwidth to 20 MHz
ESP2:MSR:RFBW 20MHZ
//Calculate limits for MSR SEM
ESP2:MSR:APPL
Manual operation:
See " Apply to SEM " on page 234
[SENSe:]ESPectrum<sb>:MSR:BAND <Range>
Defines the frequency range of the bands used by the base station.
Configuring and Performing Measurements
