PEAK
Measures the highest peak within the reference range.
CPOWer
Measures the channel power within the reference range (integral
bandwidth method).
*RST: CPOWer
Manual operation: See " Power Reference Type " on page 229
14.5.6.6 Configuring the Power Classes
The following commands define the power classes for SEM measurements.
CALCulate<n>:LIMit<li>:ESPectrum<sb>:LIMits................................................................810
CALCulate<n>:LIMit<li>:ESPectrum<sb>:MODE...............................................................811
CALCulate<n>:LIMit<li>:ESPectrum<sb>:VALue............................................................... 811
CALCulate<n>:LIMit<li>:ESPectrum<sb>:PCLass<pc>:COUNt...........................................812
CALCulate<n>:LIMit<li>:ESPectrum<sb>:PCLass<pc>[:EXCLusive]................................... 812
CALCulate<n>:LIMit<li>:ESPectrum<sb>:PCLass<pc>:LIMit[:STATe].................................. 813
CALCulate<n>:LIMit<li>:ESPectrum<sb>:PCLass<pc>:MAXimum...................................... 814
CALCulate<n>:LIMit<li>:ESPectrum<sb>:PCLass<pc>:MINimum....................................... 814
CALCulate<n>:LIMit<li>:ESPectrum<sb>:LIMits <Max1>,<Max2>,<Max3>
This command sets or queries up to 4 power classes in one step. You can only define
values for the number of power classes defined by CALCulate<n>:LIMit<li>:
ESPectrum<sb>:PCLass<pc>:COUNt on page 812.
Suffix:
<n>
.
irrelevant
<li> irrelevant
<sb>
Setting parameters:
<Max1> Defines the value range for power class 1 as -200 to
<Max1>.
Only available for CALC:LIM:ESP:PCL:COUNT >=2
If only 2 power classes are defined, the value range for power
class 2 is defined as <Max1> to 200.
Range: -199 to + 199
Default unit: DBM
<Max2> Defines the value range for power class 2 as <Max1> to
<Max2>.
Only available for CALC:LIM:ESP:PCL:COUNT >=3
If only 3 power classes are defined, the value range for power
class 3 is defined as <Max2> to 200.
Range: -199 to + 199, <Max2> must be higher than
<Max1>
