Remote Control Commands
R&S
®
SMB100A
361Operating Manual 1407.0806.32 ─ 21
Example:
MMEM:CDIR '/var/Listmode'
selects the directory for the list mode files.
LIST:DEL 'LIST1'
deletes the list list1.
Usage: Setting only
Manual operation: See "List Mode Data... - List Mode" on page 191
[:SOURce<hw>]:LIST:DELete:ALL
Deletes all lists in the selected directory.
Note: The list mode must be previously disabled to make sure that no records are
selected when you set the frequency mode ([:SOURce<hw>]:FREQuency:MODE).
The files are stored with the fixed file extensions *.lsw in a directory of the user's
choice. You can select the directory with the commands :MMEMory:CDIRectory or
[:SOURce<hw>]:LIST:CATalog?.
*RST does not affect data lists.
Example:
MMEM:CDIR '/var/Listmode'
selects the directory for the list mode files.
FREQ:MODE SWE
deactivates the list mode for RF output and activates the sweep
mode.
LIST:DEL:ALL
deletes all list mode files in the selected directory.
Usage: Event
Manual operation: See "List Mode Data... - List Mode" on page 191
[:SOURce<hw>]:LIST:DEXChange:AFILe:CATalog?
Queries the available ASCII files for export or import of list mode data in the current or
specified directory.
As response, you get a string containing the existing ASCII files *.txt or *.csv, sep-
arated by commas.
Return values:
<Catalog> string
Example:
MMEM:CDIR '/var/import'
selects the directory for the ASCII files with frequency and level
value pairs.
LIST:DEXC:AFIL:EXT TXT
determines the extension *.txt for the query.
LIST:DEXC:AFIL:CAT?
queries the available files with extension *.txt.
Response:'list1,list2'
the ASCII files list1.txt and list2.txt are available.
SOURce Subsystem
