Remote Control Commands
R&S
®
SMB100A
362Operating Manual 1407.0806.32 ─ 21
Usage: Query only
[:SOURce<hw>]:LIST:DEXChange:AFILe:EXTension <Extension>
Determines the extension of the ASCII file for import or export, or to query existing
files.
Parameters:
<Extension> TXT | CSV
*RST: TXT
Example:
MMEM:CDIR '/var/import'
selects the directory for the ASCII files with frequency and level
value pairs.
LIST:DEXC:AFIL:EXT TXT
selects ASCII files with the extension *.txt for the query.
LIST:DEXC:AFIL:CAT?
queries the available files with extension *.txt.
Response: 'list1,list2'
the ASCII files list1.txt and list2.txt exist.
Manual operation: See "Extension - List Mode" on page 194
[:SOURce<hw>]:LIST:DEXChange:AFILe:SELect <Filename>
Selects the ASCII file to be imported or exported.
Parameters:
<Filename> <ascii_file_name>
Example:
LIST:DEXC:MODE IMP
determines that ASCII files with frequency and level value pairs
are imported into list mode lists.
LIST:DEXC:AFIL:EXT TXT
determines the extension *.txt for the query.
LIST:DEXC:AFIL:CAT?
queries the available files with extension *.txt.
Response: 'list1,list2'
the ASCII files list1.txt and list2.txt exist.
LIST:DEXC:AFIL:SEL '/var/list.csv'
selects list.csv for import.
LIST:DEXC:SEL '/var/list_imp'
determines the destination file list_imp.
LIST:DEXC:EXEC
imports the ASCII file data into the list file.
Manual operation:
See "Select ASCII Source / Destination - List Mode"
on page 194
SOURce Subsystem
