Remote Control Commands

R&S

SMB100A

363Operating Manual 1407.0806.32 ─ 21

[:SOURce<hw>]:LIST:DEXChange:AFILe:SEParator:COLumn <Column>

Selects the separator between the frequency and level column of the ASCII table.

Parameters:

<Column> TABulator | SEMicolon | COMMa | SPACe

*RST: COMMa

Example:

LIST:DEXC:MODE EXP

selects that the list is exported into an ASCII file.

LIST:DEXC:AFIL:SEL '/var/list.csv'

determines ASCII file list.csv as destination for the list mode list

data.

LIST:DEXC:AFIL:SEP:COL TAB

defines a tabulator to separate the frequency and level values

pairs.

LIST:DEXC:AFIL:SEP:DEC DOT

selects the decimal separator dot.

LIST:DEXC:SEL '/var/list_imp'

determines the source file list_imp for export into the ASCII file

list.csv.

LIST:DEXC:EXEC

exports the list file data into the ASCII file.

Manual operation:

See "Column Separator- List Mode" on page 194

[:SOURce<hw>]:LIST:DEXChange:AFILe:SEParator:DECimal <Decimal>

Sets the decimal separator used in the ASCII data between '.' (decimal point) and ','

(comma) with floating-point numerals.

Parameters:

<Decimal> DOT | COMMa

*RST: DOT

Example: see [:SOURce<hw>]:LIST:DEXChange:AFILe:

SEParator:COLumn on page 363

Manual operation: See "Decimal Point - List Mode" on page 194

[:SOURce<hw>]:LIST:DEXChange:EXECute

Executes the import or export of the selected list file, according to the previously set

transfer direction with command [:SOURce<hw>]:LIST:DEXChange:MODE.

SOURce Subsystem
