R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
369Operating Manual 1407.0806.32 ─ 21
Parameters:
<Power> <Power#1>{, <Power#2>, ...} | block data
The data can be given either as a list of numbers (list can be of
any length and list entries must be separated by commas) or as
binary block data. When block data is transferred, 8 bytes are
always interpreted as a floating-point number with double accu-
racy (see :FORMat[:DATA] on page 294).
Range: Minimum level to Maximum level
Default unit: dBm
Example:
LIST:SEL '/var/list3'
selects list3 for editing. The R&S SMB generates a new file
automatically, if it does not exist yet.
LIST:POW 0dBm, 2dBm, 2dBm, 3dBm,..
specifies the level values in list3. The number of level values
must correspond to the number of frequency values. The previ-
ous data is overwritten.
Manual operation: See "Edit List Mode Data... - List Mode" on page 192
[:SOURce<hw>]:LIST:POWer:POINts?
Queries the length (in points) of the LEVel part of the selected list.
Return values:
<Points> integer
Range: 0 to INT_MAX
*RST: 0
Example:
LIST:SEL '/var/list3'
selects list3 for editing. The R&S SMB generates a new file
automatically, if it does not exist yet.
LIST:POW:POIN?
queries the number of levels in the list file
Response: 327
Usage: Query only
[:SOURce<hw>]:LIST:RESet
Resets the list to the starting point.
Example:
LIST:RES
resets the list to the starting point.
Usage: Event
Manual operation: See "Reset - List Mode" on page 190
SOURce Subsystem
