Preparing for Use
R&S
®
SMB100A
43Operating Manual 1407.0806.32 ─ 21
Note: The VNC Viewer program is included in the download for the installation of
the Ultr@VNC program on the signal generator if "Full installation" was selected in
the "Select Component" panel. In this case, the program ultr@vncviewer.exe
can be copied to the Windows PC.
2. Install VNC Viewer program component on the remote computer.
Setting up the VNC connection on the Linux/Unix remote computer
The VNC program is available per default for Linux/Unix operating systems.
1. Start a Web browser on the remote computer and enter the IP address of the
instrument.
2. Enter the following address:
vnc://<IP-address of the instrument>, e.g. vnc://192.168.1.1.
A dialog is opened and the password for the remote VNC connection is requested.
3. Enter the password as defined in the "Default Local System Properties" panel of
the Ultr@VNC program and select "Log On".
The connection is established, the instrument is remote accessed and the current
signal generator screen with the block diagram is displayed. The individual func-
tions are operated using the mouse and keyboard.
In contrast to remote access via Remote Desktop, the direct control of the instru-
ment is not disabled and the instrument can be controlled from the front panel and
via the remote computer alternately.
Setting up the VNC connection on the Windows remote computer
1. Start VNC Viewer program component on the PC, select "VNC Server" and enter
IP address of the instrument.
2. To initialize the connection, select "Connect".
A message requesting the password appears.
Remote Access via an External Controller
