D163 44 SM
14. Disconnect the flat cable from the new FCU board.
15. Re-assemble the machine.
16. Turn on the main power switch, then do SP6-101 to print the system parameter list.
17. Check the system parameter list to make sure that the data is transferred correctly.
18. Set the correct date and time with the User Tools: User Tools > System Settings >
Timer Setting > Set Date/Time.
If any of the SRAM data was not transferred, input those settings manually.
For D146/D147 models
1. Remove the controller box cover [A] ( x 4).
2. Remove the interface slot cover [A] (
x 2).
3. Pull out the FCU [A] from the interface slot.
To Next Page
