Pick-up Roller, Feed Roller, Friction Roller

D693 16 SM

1.10 PICK-UP ROLLER, FEED ROLLER, FRICTION ROLLER

1. Paper feed unit ( page 10, page 14)

2. Holder [A] (

×1)

3. Pick-up roller [A]
