Paper Exit
D146/D147/D148/D149/D150 4-112 SM
4.13 PAPER EXIT
4.13.1 PAPER EXIT UNIT
1. Open the right cover (page 4-134 "Duplex Unit")
2. Fusing unit (page 4-99 "Fusing Unit")
3. Inner cover [A] (
×2)
4. Paper exit unit [A] (
×1, ×2)
4.13.2 PAPER EXIT SWITCHING SOLENOID
1. Paper exit unit (page 4-112 "Paper Exit Unit")
2. Paper exit switching solenoid [A] ( ×2, ×1, ×1)
