Bottom Plate Position Sensor

SM 27 D683

SPDF DF3080

(D683)

1.21 BOTTOM PLATE POSITION SENSOR

1. ADF rear cover (page 8 "ADF Rear Cover")

2. Original feed unit (page 10 "Original Feed Unit")

3. Bottom plate position sensor [A] (

×1)
