Registration Sensor

SM 17 D779

ARDF DF3090

(D779)

1.13 REGISTRATION SENSOR

1. Open the left cover.

2. Original feed unit (

page 3)

3. Original tray (

page 2)

4. Original feed-in guide plate (

page 10)

5. Registration sensor [A] (

x 1)
