Tray Lift Motor

SM 11 D690

INTERNAL

FINISHER

SR3130

(D690)

1.9 TRAY LIFT MOTOR

1. Paper exit tray ( page 5)

2. Tray lift motor unit [A] (

×2, ×1, ×1)

3. Cam [A], shaft [B] (

×1)

4. Tray lift motor [A] (

×2)
