Original Set Sensor

D683 24 SM

1.18 ORIGINAL SET SENSOR

1. ADF front cover (page 7 "ADF Front Cover")

2. Remove the screw and raise the original tray [A] (

×1)

3. Original set sensor [A] (

×1, ×1)
