Ricoh D147 - Paper Feed Solenoid

To Next Page

To Previous Page

Paper Feed

D146/D147/D148/D149/D150 4-122 SM

4.14.4 PAPER FEED SOLENOID

§ Note that the mounting part in the 1st paper feed solenoid is different from the one for the

2nd paper feed solenoid.

1. Paper feed unit (page 4-117 "Paper Feed Unit")

2. Paper feed solenoid [A] (

×1, ×1)
