Ricoh D147 - Paper Path

To Next Page

To Previous Page

Product Overview

SM 1-15 D146/D147/D148/D149/D150

Product

Information

1.1.2 PAPER PATH

No. Description No. Description

1 SPDF DF3080 4 Booklet Finisher SR3150

2 LCIT RT3030 5 Bridge Unit BU3070

3 LCIT PB3170
