Intermediate transport (left) paper surface sensor

D686/D687 18 SM

1.8 INTERMEDIATE TRANSPORT (LEFT) PAPER

SURFACE SENSOR

1. Proof tray ( page 7)

2. Intermediate transport (left) paper surface sensor bracket [A] (

×1, ×1, ×1)

3. Intermediate transport (left) paper surface sensor [A]
