Pick-up Solenoid

SM 21 D779

ARDF DF3090

(D779)

1.16 PICK-UP SOLENOID

1. Rear cover ( page 1)

2. Harness guide (

page 19)

3. Pick-up solenoid [B] (

x 2, x 1)
