Ricoh D147 - Copy Data Security Unit Type G; Accessory Check; Installation Procedure

Copy Data Security Unit Type G
SM 2-159 D146/D147/D148/D149/D150
Installation
2.29 COPY DATA SECURITY UNIT TYPE G
2.29.1 ACCESSORY CHECK
No. Description Q’ty
1 Copy data security unit board 1
2 Screws 2
2.29.2 INSTALLATION PROCEDURE
§ When you install this option, switch the MFP’s power supply OFF, and unplug the power
plug from the mains outlet.
§ If it is installed when the power is on, it will result in an electric shock or malfunction.
1. Rear cover (page 4-10 "Rear Cover")
2. Attach the bracket [A] to the copy data security module [B] (
×2)
