Ricoh D147 - Original Exit Sensor

Original Exit Sensor
D779 16 SM
1.12 ORIGINAL EXIT SENSOR
1. Open the left cover.
2. Original feed unit (
page 3)
3. Original tray (
page 2)
4. Original feed-in guide plate (
page 10)
5. The Original Exit Sensor is located in the ARDF mainframe [A].
6. Original exit sensor bracket [A]
7. Original exit sensor [A]
