Service Call 501-584
D146/D147/D148/D149/D150 5-58 SM
SC No. Level Error Name/Error Condition/Major Cause/Solution
§ Reset the paper
§ Remove the foreign matter
§ Replace the motor
§ Reset the connector
§ Replace the harness
§ Replace the sensor
§ Replace the control board for the optional side LCT
§ Replace the tray
§ Replace the timing belt
§ Replace the timing pulley
§ Replace the base plate
SC505-43 B Side LCIT Paper Overload Error
During tray initialization, both the upper limit and lower limit are
detected for 3 times consecutively (up to 2 times consecutively,
the side LCIT transmits a "tray set fault" to the main machine.
§ Paper overload
§ Paper set fault
§ Limit sensor error/connector missing
§ Lower limit sensor error/connector missing
§ Harness broken
§ Bank control board defective
§ Foreign matter, such as paper scrap, is caught inside the
tray
§ Reset the paper
§ Remove the foreign matter
§ Reset the connector
§ Replace the harness
§ Replace the sensor
§ Replace the control board for the optional side LCT
