Jam Detection
D146/D147/D148/D149/D150 5-208 SM
Cause code Cause of jam Display code
183 Jam in tray ascent/descent motor R1-R5
184 Jam in shift motor R1-R5
185 Jam in shift jogger front motor R1-R5
186 Jam in shift jogger rear motor R1-R5
187 Jam in shift jogger retreat motor R1-R5
188 Jam in return roller rocking motor R1-R5
189 Jam in edge guide motor R1-R5
190 Jam due to main instruction data defect R1-R5
Booklet Finisher SR3170
Cause code Cause of jam Display code
1 There is paper in inlet sensor R1-R5
1 There is paper in horizontal transport
sensor
R1-R5
1 There is paper in switchback transport
sensor
R1-R5
1 There is paper in proof output sensor R1-R5
1 There is paper in shift output sensor R1-R5
1 There is paper in saddle stitch output
sensor
R6-R11
150 Jam due to paper not reaching inlet sensor R1-R5
151 Jam due to hold up at inlet sensor R1-R5
152 Jam due to paper not reaching horizontal
transport sensor
R1-R5
153 Jam due to paper held up at horizontal
transport sensor
R1-R5
