Kinetix 5500 Servo Drives
Linear Motion Performance Specifications
These linear motion families are compatible with Kinetix 5500 servo drives.
For Kinetix 5500 drive system combinations that include cable catalog number selection and force/velocity curves, refer to the Kinetix 5500
Drive Systems Design Guide, publication KNX-RM009
.
LDAT-Series Performance Specifications with Kinetix 5500 Drives
These actuators require the 2198-H2DCK feedback converter kit.
Performance Specifications with 200V-class Drive Operation and Frame 30 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Motion Family Page
LDAT-Series integrated linear thrusters 68
Kinetix MPAS integrated linear stages 72
Kinetix VPAR electric cylinders 108
Kinetix MPAR electric cylinders 73
Kinetix MPAI heavy-duty electric cylinders 74
IMPORTANT These system combinations do not include all possible actuator/drive combinations. Refer to Motion Analyzer to verify
compatibility. To access Motion Analyzer, go to: https://motionanalyzer.rockwellautomation.com
.
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 5500 Drives
(240V AC input)
LDAT-S031010-DDx 2.4
4.8 81 (18) 12.2 168 (38)
0.20
2198-H015-ERSx
LDAT-S031020-DDx 3.1 0.25
LDAT-S031030-DDx 3.5 0.29
LDAT-S031040-DDx 3.8 0.31
LDAT-S032010-DDx 3.1
7.4
126 (28)
24.3
336 (76)
0.44
2198-H025-ERSx
LDAT-S032020-DDx 4.1 0.52
LDAT-S032030-DDx 4.7 0.59
LDAT-S032040-DDx 5.0 0.63
LDAT-S032010-EDx 3.1
3.7 12.2
0.40
2198-H015-ERSx
LDAT-S032020-EDx 4.1 0.47
LDAT-S032030-EDx 4.7 0.52
LDAT-S032040-EDx 5.0 0.55
LDAT-S033010-DDx 3.5
11.1
190 (43)
36.5
504 (113)
0.67
2198-H040-ERSx
LDAT-S033020-DDx 4.7 0.88
LDAT-S033030-DDx
5.0 0.95
LDAT-S033040-DD
x
LDAT-S033010-EDx 3.5
3.7 12.2
0.55
2198-H015-ERSx
LDAT-S033020-EDx
4.4 0.65LDAT-S033030-EDx
LDAT-S033040-EDx
