Kinetix 5700 Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
VPL-B1651C 2750 2750 10.21 11.50 (102)
28.20 21.68 (192)
2.32 (3.11)
2198-D020-ERSx
29.29 22.45 (199) 2198-D032-ERSx
VPL-B1651F 4750 4750 17.60 11.43 (101)
45.90 18.02 (159)
4.38 (5.87)
2198-D032-ERSx
57.27 22.45 (199) 2198-D057-ERSx
VPL-B1652C 2700 2700 16.0 19.40 (172)
45.90 44.78 (396)
4.18 (5.60)
2198-D032-ERSx
49.88 48.60 (430) 2198-D057-ERSx
VPL-B1652F 4000 4000 18.60 17.60 (156) 60.00 48.60 (430) 4.77 (6.40) 2198-D057-ERSx
VPL-B1653C 2300 2300 17.75 25.76 (228)
45.90 55.14 (488)
4.38 (5.87)
2198-D032-ERSx
55.60 66.70 (590) 2198-D057-ERSx
VPL-B1653D 3000 3000 18.60 24.20 (214) 68.00 67.80 (600) 5.50 (7.30) 2198-D057-ERSx
VPL-B1654B 1850 1850 15.54 32.97 (292)
45.90 65.38 (578)
5.55 (7.44)
2198-D032-ERSx
55.75 79.30 (702) 2198-D057-ERSx
VPL-B1654D 3000 3000 24.47 32.0 (283) 81.30 75.30 (666) 7.16 (9.60) 2198-D057-ERSx
Kinetix VPC Motor Performance Specifications with Kinetix 5700 Drives
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum Speed
(bus overvoltage speed)
(1)
rpm
(1) Operation beyond this speed requires DC-bus protection. See the Kinetix 5700 Servo Drives User Manual, publication 2198-UM002
, for more information on bus overvoltage speed, field-
weakening mode, and the extended speed feature.
System Continuous
Stall Current
A (0-pk)
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
VPC-B1652A 1500 4500 (2347) 11.2 25.5 (226) 19.3 40.3 (357) 4.0 (5.4) 2198-D020-ERSx
VPC-B1652D 3000 5000 (4452) 15.6 17.6 (156) 38.0 40.7 (360) 5.5 (7.4) 2198-D032-ERSx
VPC-B1653A 1500 4500 (2310) 15.7 35.1 (311) 28.5 60.6 (536) 5.5 (7.4) 2198-D032-ERSx
VPC-B1653D 3000 5000 (4294) 21.4 24.0 (212) 56.3 61.4 (543) 7.5 (10.1) 2198-D057-ERSx
VPC-B1654D 3000 5000 (4494) 30.2 35.1 (311) 75.1 76.6 (678) 11.0 (14.7) 2198-D057-ERSx
VPC-B21539 1000 3000 (1573) 15.6 52.5 (465) 41.6 118.8 (1051) 5.5 (7.4) 2198-D032-ERSx
VPC-B2153A 1500 4500 (2325) 21.2 48.0 (425) 57.2 111.8 (990) 7.5 (10.1) 2198-D057-ERSx
VPC-B21549 1000 3000 (1573) 21.7 72.0 (637) 54.3 158.4 (1402) 7.5 (10.1) 2198-D057-ERSx
VPC-B2154A 1500 4500 (2333) 30.8 70.1 (620) 72.1 140.1 (1240) 11.0 (14.7) 2198-D057-ERSx
VPC-B2154D 3000 5000 (4294) 41.0 48.0 (425) 120.1 131.4 (1163) 15.0 (20.1) 2198-S086-ERSx
VPC-B2155D 3000 5000 (4172) 48.8 59.0 (522)
121.6 138.6 (1227)
18.5 (24.8)
2198-S086-ERSx
139.5 156.7 (1387) 2198-S130-ERSx
VPC-B2156D 3000 5000 (4101) 57.6 70.1 (620)
121.6 139.3 (1233)
22.0 (29.5)
2198-S086-ERSx
171.6 185.5 (1642) 2198-S130-ERSx
VPC-B30029 1000 3000 (1493) 29.2 105.1 (930) 56.9 183.7 (1626) 11.0 (14.7) 2198-S086-ERSx
VPC-B3002A 1500 4000 (2212) 39.6 95.5 (845) 82.9 170.4 (1508) 15.0 (20.1) 2198-S086-ERSx
VPC-B30039 1000 3000 (1472) 38.0 143.3 (1268) 72.2 237.9 (2106) 15.0 (20.1) 2198-S086-ERSx
VPC-B3003A 1500 3500 (2166) 56.3 140.3 (1242) 108.0 244.8 (2167) 22.0 (29.5) 2198-S086-ERSx
VPC-B30049 1000 3000 (1429) 46.6 176.7 (1564) 96.6 327.8 (2901) 18.5 (24.8) 2198-S086-ERSx
VPC-B3004A 1500 3500 (2128) 77.6 191.1 (1691) 145.2 319.0 (2823) 30.0 (40.2) 2198-S130-ERSx
VPC-B3004D 3000 4000 (4054) 76.6 95.5 (845)
183.8 225.8 (1998)
30.0 (40.2)
2198-S130-ERSx
211.1 257.7 (2281) 2198-S160-ERSx
Kinetix VPL Motor Performance Specifications with Kinetix 5700 (400V operation) Drives (continued)
Motor Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A (0-pk)
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
To Next Page
