Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 107
Kinetix 5500 Servo Drives
Performance Specifications with 400V-class Drive Operation and Frame 150 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPAS Performance Specifications with Kinetix 5500 Drives
These actuators require the 2198-H2DCK feedback converter kit.
Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
460V AC
kW
Kinetix 5500 Drives
(480V AC input)
LDAT-S152010-DDx 3.2
5.3
643 (145)
19.5
1799 (404)
1.76
2198-H025-ERSx
LDAT-S152020-DDx
…
LDAT-S152090-DDx
3.5 1.89
LDAT-S152010-EDx
…
LDAT-S152090-EDx
1.8 2.7 9.8 0.87 2198-H015-ERSx
LDAT-S153010-DDx
…
LDAT-S153090-DDx
3.6 8.0
978 (220)
29.1
2680 (602)
2.87 2198-H040-ERSx
LDAT-S153010-EDx
…
LDAT-S153090-EDx
1.2 2.7 9.1 0.80 2198-H015-ERSx
LDAT-S154010-DDx
…
LDAT-S154090-DDx
3.5 10.7
1306 (294)
39.1
3597 (809)
3.83 2198-H040-ERSx
LDAT-S154010-EDx
…
LDAT-S154090-EDx
1.8 5.3 19.5 1.78 2198-H025-ERSx
LDAT-S156010-DDx
…
LDAT-S156090-DDx
3.6 16.3
1997 (449)
59.4
5469 (1229)
5.85 2198-H070-ERSx
LDAT-S156010-EDx
…
LDAT-S156090-EDx
1.8 8.1 19.8 2.71 2198-H025-ERSx
Linear Stage Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5500 Drives
(240V AC input)
MPAS-Axxxx1-V05SxA
200 (7.9)
(1)
(1) For 900 mm stroke length, maximum speed is 176 mm/s (6.9 in/s). For 1020 mm stroke length, maximum speed is 143 mm/s (5.6 in/s).
3.09 521 (117) 6.10 1212 (272) 0.37 2198-H008-ERSx
MPAS-Axxxx2-V20SxA
1124 (44.3)
(2)
(2) For 780 mm stroke length, maximum speed is 889 mm/s (35.0 in/s). For 900 mm stroke length, maximum speed is 715 mm/s (28.2 in/s). For 1020 mm stroke length, maximum speed is
582 mm/s (22.9 in/s).
4.54 462 (104) 9.10 968 (218) 0.62 2198-H015-ERSx
Linear Stage Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5500 Drives
(480V AC input)
MPAS-Bxxxx1-V05SxA
200 (7.9)
(1)
(1) For 900 mm stroke length, maximum speed is 176 mm/s (6.9 in/s). For 1020 mm stroke length, maximum speed is 143 mm/s (5.6 in/s).
1.75 521 (117) 3.50 1212 (272) 0.37 2198-H008-ERSx
MPAS-Bxxxx2-V20SxA
1124 (44.3)
(2)
(2) For 780 mm stroke length, maximum speed is 889 mm/s (35.0 in/s). For 900 mm stroke length, maximum speed is 715 mm/s (28.2 in/s). For 1020 mm stroke length,
maximum speed is 582 mm/s (22.9 in/s).
3.30 462 (104) 6.60 968 (218) 0.62 2198-H008-ERSx
