Rockwell Automation Allen-Bradley Kinetix 5700 Selection Guide

216 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 300 and Kinetix 350 EtherNet/IP Servo Drives
Kinetix TLY Motor Performance Specifications with Kinetix 300/350 Drives
Performance Specifications (non-brake) with Kinetix 300/350 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance Specifications (brake) with Kinetix 300/350 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 300/350
200V-class Single-phase
or Three-phase Drives
TLY-A110x 5000
6000
(1)
(1) Applies to TLY-AxxxT-H motors with incremental feedback. The TLY-AxxxT-B motors with absolute high-resolution encoders are rated for 5000 rpm.
0.55 0.096 (0.85) 1.50 0.20 (1.75) 0.041
2097-V33PR1-xx
2097-V32PR0-xx
2097-V31PR0-xx
TLY-A120x 5000 1.03 0.181 (1.60) 2.50 0.36 (3.20) 0.086
2097-V33PR1-xx
2097-V32PR0-xx
2097-V31PR0-xx
TLY-A130x 5000 1.85 0.325 (2.88) 4.90 0.76 (6.70) 0.14
2097-V33PR1-xx
2097-V32PR0-xx
2097-V31PR0-xx
TLY-A220x 5000 3.50 0.836 (7.40) 7.90 1.48 (13.1) 0.35
2097-V33PR1-xx
2097-V32PR0-xx
2097-V31PR0-xx
TLY-A230x 5000 5.50 1.30 (11.5) 15.5 3.05 (27.0) 0.44
2097-V33PR3-xx
2097-V32PR2-xx
2097-V31PR2-xx
TLY-A2530P 4400
5000
10.0 2.60 (23.0) 21.0 5.20 (46.0) 0.69
2097-V33PR5-xx
2097-V32PR4-xx
TLY-A2540P 4575 10.0 2.94 (26.0) 24.8 7.10 (63.0) 0.86
2097-V33PR5-xx
2097-V32PR4-xx
TLY-A310M 4000 4500 10.0 3.61 (31.9) 30.0 9.0 (79.6) 0.95
2097-V33PR5-xx
2097-V32PR4-xx
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 300/350
200V-class Single-phase
or Three-phase Drives
TLY-A110x 5000
6000
(1)
(1) Applies to TLY-AxxxT-H motors with incremental feedback. The TLY-AxxxT-B motors with absolute high-resolution encoders are rated for 5000 rpm.
0.50 0.086 (0.76) 1.50 0.20 (1.75) 0.037
2097-V33PR1-xx
2097-V32PR0-xx
2097-V31PR0-xx
TLY-A120x 5000 0.93 0.163 (1.44) 2.50 0.36 (3.20) 0.077
2097-V33PR1-xx
2097-V32PR0-xx
2097-V31PR0-xx
TLY-A130x 5000 1.67 0.293 (2.59) 4.90 0.76 (6.70) 0.13
2097-V33PR1-xx
2097-V32PR0-xx
2097-V31PR0-xx
TLY-A220x 5000 3.15 0.757 (6.70) 7.90 1.48 (13.1) 0.24
2097-V33PR1-xx
2097-V32PR0-xx
2097-V31PR0-xx
TLY-A230x 4250 4.95 1.16 (10.3) 15.5 3.05 (27.0) 0.32
2097-V33PR3-xx
2097-V32PR2-xx
2097-V31PR2-xx
TLY-A2530P 3650
5000
10.0 2.60 (23.0) 21.0 5.20 (46.0) 0.55
2097-V33PR5-xx
2097-V32PR4-xx
TLY-A2540P 3750 10.0 2.94 (26.0) 24.8 7.10 (63.0) 0.66
2097-V33PR5-xx
2097-V32PR4-xx
TLY-A310M 3900 4500 10.0 3.61 (31.9) 30.0 9.0 (79.6) 0.90
2097-V33PR5-xx
2097-V32PR4-xx
