Kinetix 5500 Servo Drives
Kinetix VPL Motor Performance Specifications with Kinetix 5500 Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Motor Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5500 Drives
(240V AC input)
VPL-A0631E 4500 4500 1.20 0.46 (4.0)
3.50 1.12 (9.91)
0.19 (0.25)
2198-H003-ERSx
4.20 1.33 (12.0) 2198-H008-ERSx
VPL-A0631M 7200 7200 1.92 0.46 (4.0) 6.48 1.33 (12.0) 0.28 (0.38) 2198-H008-ERSx
VPL-A0632F 4800 4800 2.55 0.93 (8.0) 8.75 2.69 (24.0) 0.39 (0.52) 2198-H008-ERSx
VPL-A0633C 3000 3000 2.50 1.27 (11.0) 8.75 4.09 (36.0) 0.37 (0.50) 2198-H008-ERSx
VPL-A0633F 4500 4500 3.52 1.27 (11.0)
8.80 2.87 (25.0)
0.44 (0.59)
2198-H008-ERSx
12.60 4.09 (36.0) 2198-H015-ERSx
VPL-A0751E 4800 4800 2.90 1.01 (9.0)
8.80 2.20 (19.0)
0.50 (0.67)
2198-H008-ERSx
9.12 2.27 (20.0) 2198-H015-ERSx
VPL-A0752C 3300 3300 3.80 1.61 (14.0) 13.30 4.39 (39.0) 0.49 (0.66) 2198-H015-ERSx
VPL-A0752E 4800 4800 4.90 1.61 (14.0)
17.70 4.10 (36.0)
0.66 (0.88)
2198-H015-ERSx
18.90 4.39 (39.0) 2198-H025-ERSx
VPL-A0753C 3300 3300 4.09 2.16 (19.0)
17.70 6.55 (58.0)
0.59 (0.79)
2198-H015-ERSx
18.90 7.02 (62.0) 2198-H025-ERSx
VPL-A0753E 4600 4600 6.12 2.28 (20.0)
17.70 5.13 (45.0)
0.80 (1.07)
2198-H015-ERSx
25.34 7.35 (65.0) 2198-H025-ERSx
VPL-A1001C 2800 2800 3.61 1.93 (17.0) 10.38
3.22 (28.0)
0.56 (0.75)
2198-H008-ERSx
3.78 (33.0) 2198-H015-ERSx
VPL-A1001M 6500 6500 7.15 1.95 (17.0) 20.20
3.31 (29.0)
1.29 (1.73)
2198-H015-ERSx
3.78 (33.0) 2198-H025-ERSx
VPL-A1002C 3000 3000 6.24 3.39 (30.0) 20.33
6.80 (60.0)
1.03 (1.38)
2198-H015-ERSx
7.82 (69.0) 2198-H025-ERSx
VPL-A1002F 5000 5000 10.04 3.26 (29.0) 34.30
6.77 (60.0)
1.60 (2.14)
2198-H025-ERSx
7.82 (69.0) 2198-H040-ERSx
VPL-A1003C 2250 2250 6.14 4.18 (37.0) 20.20
9.76 (86.0)
0.87 (1.17)
2198-H015-ERSx
11.15 (99.0) 2198-H025-ERSx
VPL-A1003E 3750 3750 9.58 4.18 (37.0) 28.80
9.76 (86.0)
1.31 (1.76)
2198-H025-ERSx
11.15 (99.0) 2198-H040-ERSx
VPL-A1003F 5500 5500 15.62 4.18 (37.0) 50.0
10.25 (90.0)
1.90 (2.55)
2198-H040-ERSx
11.15 (99.0) 2198-H070-ERSx
VPL-A1152B 2150 2150 6.17 5.10 (45.0) 21.19
10.95 (96.0)
1.02 (1.37)
2198-H015-ERSx
13.12 (116) 2198-H025-ERSx
VPL-A1152E 3300 3300 10.60 5.08 (45.0) 32.10
12.14 (107)
1.47 (1.97)
2198-H025-ERSx
13.12 (116) 2198-H040-ERSx
VPL-A1152F 5000 5000 13.56 4.70 (42.0) 45.80 13.12 (116) 2.16 (2.90) 2198-H040-ERSx
VPL-A1153C 2300 2300 8.88 6.55 (58.0) 33.0
18.30 (162)
1.35 (1.81)
2198-H025-ERSx
20.33 (180) 2198-H040-ERSx
VPL-A1303B 1950 1950 10.34 8.80 (78.0) 31.0
19.85 (175)
1.61 (2.16)
2198-H025-ERSx
20.72 (183) 2198-H040-ERSx
VPL-A1303F 4000 4000 18.60 7.75 (69.0) 62.0
15.36 (136)
2.50 (3.35)
2198-H040-ERSx
20.72 (183) 2198-H070-ERSx
VPL-A1304A 1600 1600 9.43 10.29 (91.0) 33.76
25.03 (221)
1.55 (2.08)
2198-H025-ERSx
28.45 (252) 2198-H040-ERSx
VPL-A1304D 3000 3000 18.40 10.20 (90.0) 58.0
21.48 (190)
2.60 (3.50)
2198-H040-ERSx
27.10 (240) 2198-H070-ERSx
VPL-A1306C 2000 2000 14.78 13.38 (118) 55.83
28.50 (252)
2.13 (2.86)
2198-H040-ERSx
34.62 (306) 2198-H070-ERSx
