Rockwell Automation Allen-Bradley Kinetix 5700 Selection Guide

66 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 5700 Servo Drives
Kinetix MPF Motor Performance Specifications with Kinetix 5700 Drives
Kinetix MPF Motor Performance Specifications with Kinetix 5700 (200V operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPS Motor Performance Specifications with Kinetix 5700 Drives
Kinetix MPS Motor Performance Specifications with Kinetix 5700 (200V operation) Drives
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5700 Drives
(240V AC input)
MPF-A310P 4750 5000 4.85 1.58 (14.0) 14.0 3.61 (31.9) 0.73 2198-D012-ERSx
MPF-A320H 3350 3500 6.10 3.05 (27.0)
17.7 7.33 (64.9)
1.0
2198-D012-ERSx
19.3 7.91 (70.0) 2198-D020-ERSx
MPF-A320P 4750 5000 9.00 3.05 (27.0)
28.3 7.59 (67.2)
1.3
2198-D020-ERSx
29.5 7.91 (70.0) 2198-D032-ERSx
MPF-A330P 5000 5000 12.0 4.18 (37.0) 38.0 11.10 (98.2) 1.6 2198-D032-ERSx
MPF-A430H 3500 3500 12.2 6.21 (55.0) 45.0 19.80 (175) 1.8 2198-D032-ERSx
MPF-A430P 5000 5000 16.80 5.99 (53.0)
45.9 14.4 (127)
1.9
2198-D032-ERSx
67.0 19.80 (175) 2198-D057-ERSx
MPF-A4530K 4000 4000 19.50 8.13 (71.9) 62.0 20.30 (179) 2.3 2198-D057-ERSx
MPF-A4540F 3000 3000 18.40 10.20 (90.3)
45.9 22.09 (195)
2.5
2198-D032-ERSx
57.4 27.10 (239) 2198-D057-ERSx
MPF-A540K 4000 4000 41.50 19.40 (172) 120.0 48.60 (430) 4.1 2198-S086-ERSx
Kinetix MPF Motor Performance Specifications with Kinetix 5700 (400V operation) Drives
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
MPF-B310P 5000 5000 2.30 1.60 (14) 7.10 3.6 (32) 0.77 2198-D006-ERSx
MPF-B320P 5000 5000 4.24 3.10 (27) 14.0 7.8 (69) 1.5 2198-D012-ERSx
MPF-B330P500050005.70 4.18 (37)
17.6 10.4 (92.0)
1.6
2198-D012-ERSx
19.0 11.1 (98) 2198-D020-ERSx
MPF-B430P500050009.20 6.55 (58)
28.2 17.6 (156)
2.0
2198-D020-ERSx
32.0 19.8 (175) 2198-D032-ERSx
MPF-B4530K 4000 4000 9.90 8.25 (73)
28.2 18.7 (165)
2.4
2198-D020-ERSx
31.0 20.3 (179) 2198-D032-ERSx
MPF-B4540F 3000 3000 9.10 10.20 (90)
28.2 26.2 (232)
2.5
2198-D020-ERSx
29.0 27.1 (240) 2198-D032-ERSx
MPF-B540K 4000 4000 20.5 19.4 (171) 60.0 48.6 (430) 4.1 2198-D057-ERSx
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System
Continuous Stall
Current
A 0-pk
System
Continuous Stall
Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5700 Drives
(240V AC input)
MPS-A330P 5000 5000 9.80 3.60 (32.0)
28.3 8.79 (77.8)
1.3
2198-D020-ERSx
38.0 11.10 (98.2) 2198-D032-ERSx
MPS-A4540F 3000 3000 14.4 8.1 (72)
45.9 22.84 (202)
1.4
2198-D032-ERSx
56.0 27.1 (240) 2198-D057-ERSx
