Kinetix 5700 Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPM Motor Performance Specifications with Kinetix 5700 (400V operation) Drives
Motor Cat. No.
Base Speed
rpm
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5700 Drives
(480V AC input)
MPM-B1151F 3000 4000 5000 2.71 2.3 (20.3)
8.8 6.0 (53.1)
0.75
2198-D006-ERSx
9.9 6.6 (58.0) 2198-D012-ERSx
MPM-B1151T 6000 5000 7000 5.62 2.3 (20.3)
17.6 5.3 (46.9)
0.90
2198-D012-ERSx
20.5 5.9 (52.2) 2198-D020-ERSx
MPM-B1152C 1500 2500 3000 3.61 5.0 (44.2) 12.4 13.5 (119) 1.20 2198-D012-ERSx
MPM-B1152F 3000 4000 5200 6.17 5.0 (44.2)
17.6 11.7 (103)
1.40
2198-D012-ERSx
21.1 13.5 (119) 2198-D020-ERSx
MPM-B1152T 6000 4000 7000 11.02 5.0 (44.2)
28.2 10.7 (94.7)
1.40
2198-D020-ERSx
37.9 13.5 (119) 2198-D032-ERSx
MPM-B1153E 2250 3000 3500 6.21 6.5 (57.5)
17.6 16.9 (149)
1.40
2198-D012-ERSx
21.6 19.8 (175) 2198-D020-ERSx
MPM-B1153F 3000 4000 5500 9.20 6.5 (57.5)
28.2 17.9 (158)
1.40
2198-D020-ERSx
32.0 19.8 (175) 2198-D032-ERSx
MPM-B1153T 6000 4000 7000 15.95 6.5 (57.5)
45.9 14.8 (131)
1.45
2198-D032-ERSx
55.5 16.5(146) 2198-D057-ERSx
MPM-B1302F 3000 4000 4500 8.57 6.6 (58.4) 22.1 13.5 (119) 1.65 2198-D020-ERSx
MPM-B1302M 4500 4000 6000 12.57 6.6 (58.4) 32.4 13.5 (119) 1.65 2198-D032-ERSx
MPM-B1302T 6000 4000 7000 16.83 6.7 (59.3) 43.4 13.5 (119) 1.65 2198-D032-ERSx
MPM-B1304C 1500 1870 2750 7.00 10.3 (91.1)
17.6 22.8 (202)
2.00
2198-D012-ERSx
21.5 27.1 (240) 2198-D020-ERSx
MPM-B1304E 2250 3500 4000 10.75 10.2 (90.3)
28.2 23.4 (207)
2.20
2198-D020-ERSx
34.2 27.1 (240) 2198-D032-ERSx
MPM-B1304M 4500 3500 6000 19.02 10.4 (92.0) 60.6 27.1 (240) 2.20 2198-D057-ERSx
MPM-B1651C 1500 3000 3500 10.21 11.4 (101)
28.2 22.7 (201)
2.50
2198-D020-ERSx
29.2 23.2 (205) 2198-D032-ERSx
MPM-B1651F 3000 3000 5000 17.75 11.4 (101)
45.9 21.9 (194)
2.50
2198-D032-ERSx
50.9 23.2 (205) 2198-D057-ERSx
MPM-B1651M 4500 3000 5000 22.46 11.4 (101) 56.8 23.2 (205) 2.50 2198-D057-ERSx
MPM-B1652C 1500 2500 2500 11.51 16.0 (142) 33.6 40.0 (354) 3.80 2198-D032-ERSx
MPM-B1652E 2250 3500 3500 20.94 21.1 (187) 60.5 48.0 (425) 4.30 2198-D057-ERSx
MPM-B1652F 3000 3500 4500 28.74 21.1 (187) 84.1 48.0 (425) 4.30 2198-D057-ERSx
MPM-B1653C 1500 2000 2500 20.05 26.7 (236) 59.2 67.8 (600) 4.60 2198-D057-ERSx
MPM-B1653E 2250 3000 3500 27.00 26.8 (237) 72.9 62.0 (549) 5.10 2198-D057-ERSx
MPM-B1653F 3000 3000 4000 34.94 31.0 (274) 94.3 56.1 (496) 5.10 2198-S086-ERSx
MPM-B2152C 1500 2000 2500 27.40 36.7 (325) 55.4 72.3 (640) 5.60 2198-D057-ERSx
MPM-B2152F 3000 2500 4500 43.54 34.1 (302) 98.0 72.2 (639) 5.90 2198-S086-ERSx
MPM-B2152M 4500 2500 5000 44.58 34.1 (302) 76.3 52.9 (468) 5.90 2198-S086-ERSx
MPM-B2153B 1250 1750 2000 24.06 48.0 (425) 60.0 101 (895) 6.80 2198-D057-ERSx
MPM-B2153E 2250 2000 3000 39.63 47.9 (424) 98.6 101 (895) 7.20 2198-S086-ERSx
MPM-B2153F 3000 2000 3800 43.86 45.6 (403) 98.4 98.9 (875) 7.20 2198-S086-ERSx
MPM-B2154B 1250 1750 2000 35.46 62.7 (555) 98.0 154 (1363) 6.90 2198-S086-ERSx
MPM-B2154E 2250 2000 3000 43.68 55.9 (495) 98.3 112 (991) 7.50 2198-S086-ERSx
MPM-B2154F 3000 2000 3300 44.40 56.2 (497) 83.6 87.9 (778) 7.50 2198-S086-ERSx
