Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 171
Kinetix 6200 and Kinetix 6500 Modular Servo Drives
Kinetix MPF Motor Performance Specifications with Kinetix 6200/6500 Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPS Motor Performance Specifications with Kinetix 6200/6500 Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Motion Performance Specifications
These linear motion families are compatible with Kinetix 6200 and Kinetix 6500 servo drives.
For Kinetix 6200 and Kinetix 6500 drive system combinations that include cable catalog number selection and force/velocity curves, refer to
the Kinetix 6000 and Kinetix 6200/6500 Drive Systems Design Guide, publication KNX-RM003
.
Motor Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6200/
Kinetix 6500
400V-class Drives
MPF-B310P 5000 5000 2.30 1.60 (14) 7.10 3.6 (32) 0.77 2094-BMP5-M
MPF-B320P 5000 5000
4.0 2.90 (25.6) 9.90 6.0 (53.1)
1.5
2094-BMP5-M
4.24 3.10 (27) 14.0 7.8 (69) 2094-BM01-M
MPF-B330P 5000 5000
4.0 2.90 (25.6) 9.90 6.5 (57.5)
1.6
2094-BMP5-M
5.70 4.18 (37) 19.0 11.1 (98) 2094-BM01-M
MPF-B430P 5000 5000
8.60 6.20 (54.9) 21.5 13.9 (123)
2.0
2094-BM01-M
9.20 6.55 (58) 32.0 19.8 (175) 2094-BM02-M
MPF-B4530K 4000 4000
8.60 7.10 (62.8) 21.5 15.1 (133)
2.4
2094-BM01-M
9.90 8.25 (73) 31.0 20.3 (179) 2094-BM02-M
MPF-B4540F 3000 3000
8.60 9.50 (84.1) 21.5 20.9 (185)
2.5
2094-BM01-M
9.10 10.20 (90) 29.0 27.1 (240) 2094-BM02-M
MPF-B540K 4000 4000 20.5 19.4 (171) 60.0 48.6 (430) 4.1 2094-BM03-M
Motor Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6200/
Kinetix 6500
400V-class Drives
MPS-B330P 5000 5000
4.0 3.0 (26.5) 9.90 6.6 (58.4)
1.3
2094-BMP5-M
4.9 3.6 (32) 19.0 11.0 (97.2) 2094-BM01-M
MPS-B4540F 3000 3000 7.1 8.1 (72)
21.5 22.8 (202)
1.4
2094-BM01-M
26.0 27.1 (240) 2094-BM02-M
MPS-B560F 3000 3000 17.0 21.5 (190) 68.0 67.8 (600) 3.5 2094-BM03-M
Linear Motion Family Page
LDAT-Series integrated linear thrusters 172
Kinetix MPAS integrated linear stages 175
Kinetix MPAR electric cylinders 175
Kinetix MPAI heavy-duty electric cylinders 176
LDC-Series iron-core linear motors 177
IMPORTANT These system combinations do not include all possible actuator/drive combinations. Refer to Motion Analyzer to verify
compatibility. To access Motion Analyzer, go to: https://motionanalyzer.rockwellautomation.com
.
