122 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 5300 Single-axis EtherNet/IP Servo Drives
Performance Specifications with Kinetix 5300 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPL Motor Performance Specifications with Kinetix 5300 Drives
Performance Specifications with Kinetix 5300 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A rms
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A rms
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5300 Drives
(380/480V AC input)
TLP-B070-040 3000 6000 1.47 1.27 (11.2) 5.30 4.25 (37.6) 0.40 (0.54) 2198-C4004-ERS
TLP-B090-075 3000 6000
2.90 2.32 (20.5) 9.30 6.90 (61.1) 0.73 (0.98) 2198-C4007-ERS
2.99 2.39 (21.2) 10.85 8.05 (71.2) 0.75 (1.01) 2198-C4015-ERS
TLP-B115-100 3000 5000 4.30 3.18 (28.1) 15.11 9.34 (82.6) 1.0 (1.34) 2198-C4015-ERS
TLP-B115-200 3000 5000 7.0 6.37 (56.4)
23.80 17.90 (158.4)
2.0 (2.68)
2198-C4020-ERS
25.40 19.10 (169.0) 2198-C4030-ERS
TLP-B145-050 2000 3000 1.89 2.39 (21.2) 5.49 6.93 (61.3) 0.50 (0.67) 2198-C4007-ERS
TLP-B145-100 2000 3000 3.54 4.77 (42.4) 12.29 13.03 (115.3) 1.0 (1.34) 2198-C4015-ERS
TLP-B145-150 2000 3000 5.20 7.16 (63.4)
18.00 20.16 (178.4)
1.5 (2.01)
2198-C4015-ERS
18.34 20.54 (181.8) 2198-C4020-ERS
TLP-B145-200 2000 3000 6.85 9.55 (84.5) 21.35 24.40 (216.0) 2.0 (2.68) 2198-C4020-ERS
TLP-B145-250 3000 4500 8.60 7.96 (70.5) 33.40 26.30 (232.8) 2.5 (3.35) 2198-C4030-ERS
TLP-B200-300 1500 2500 11.65 19.1 (169.0) 34.10 47.8 (423.0) 3.0 (4.02) 2198-C4030-ERS
TLP-B200-450 1500 3000 21.18 28.7 (254.0) 58.41 67.6 (598.0) 4.5 (6.03) 2198-C4055-ERS
TLP-B200-550 1500 3000
22.60 33.49 (296.4) 58.50 73.6 (651.4) 5.3 (7.05) 2198-C4055-ERS
23.62 35.0 (310.0) 66.60 83.8 (742.0) 5.5 (7.38) 2198-C4075-ERS
TLP-B200-750 1500 2500 27.50 45.4 (401.6) 70.0 101.3 (896.0) 7.1 (9.57) 2198-C4075-ERS
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5300
(230V AC input)
MPL-A1510V 8000 8000 1.05 0.26 (2.3) 3.40 0.77 (6.8) 0.16 2198-C1004-ERS
MPL-A1520U 7000 7000 1.80 0.49 (4.3) 6.10 1.58 (13.9) 0.27 2198-C1004-ERS
MPL-A1530U 7000 7000 2.82 0.90 (8.0) 10.1 2.82 (24.9) 0.39 2198-C1004-ERS
MPL-A210V 8000 8000 3.09 0.55 (4.8) 10.2 1.52 (13.4) 0.37 2198-C1004-ERS
MPL-A220T 6000 6000 4.54 1.61 (14.2) 15.5 4.74 (41.9) 0.62 2198-C1007-ERS
MPL-A230P 5000 5000 5.40 2.10 (18.6)
21.9 7.8 (69.0)
0.86
2198-C1007-ERS
23.0 8.2 (73.0) 2198-C1015-ERS
MPL-A310F 3000 3000 3.20 1.58 (14.0) 9.19 3.61 (31.9) 0.46 2198-C1004-ERS
MPL-A310P 5000 5000 4.85 1.58 (14.0) 14.0 3.61 (31.9) 0.73 2198-C1007-ERS
MPL-A320H 3500 3500 6.10 3.05 (27.0) 19.3 7.91 (70.0) 1.0 2198-C1007-ERS
MPL-A320P 5000 5000 9.00 3.05 (27.0) 29.5 7.91 (70.0) 1.3 2198-C1015-ERS
(1)
(1) Rated peak stall-torque is specified with three-phase operation. To achieve rated peak stall-torque performance with single-phase operation, use catalog number 2198-C1020-ERS.
MPL-A330P 5000 5000 12.0 4.18 (37.0) 38.0 11.1 (98.2) 1.8 2198-C1015-ERS
(1)
MPL-A420P 5000 5000 12.7 4.79 (42.3) 46.0 13.5 (120) 2.0 2198-C1020-ERS
MPL-A430H 3500 3500 12.2 6.21 (55.0) 45.0 19.8 (175) 1.8 2198-C1020-ERS
MPL-A430P 5000 5000 16.80 5.99 (52.9) 67.0 19.8 (175) 2.2 2198-C2030-ERS
MPL-A4530F 2800 2800 13.40 8.36 (74.0) 42.0 20.3 (179) 1.9 2198-C1020-ERS
MPL-A4530K 4000 4000 19.50 8.13 (71.9) 62.0 20.3 (179) 2.5 2198-C2030-ERS
MPL-A4540C 1500 1500 9.40 10.30 (91.1) 29.0 27.1 (239) 1.5 2198-C1015-ERS
(1)
MPL-A4540F 3000 3000 18.40 10.19 (90.1) 57.39 27.1 (239) 2.6 2198-C1020-ERS
MPL-A4560F 3000 3000 22.0 14.1 (125) 66.0 34.4 (305) 3.0 2198-C2030-ERS
MPL-A520K 4000 4000 23.0 10.77 (95.2) 65.0 24.3 (215) 3.5 2198-C2030-ERS
MPL-A540K 4000 4000 41.5 19.42 (171) 120.0 48.6 (430) 5.5 2198-C2055-ERS
MPL-A560F 3000 3000 42.0 27.39 (242) 120.0 61.0 (540) 5.3 2198-C2055-ERS
