Rockwell Automation Allen-Bradley Kinetix 5700 Selection Guide

Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 59
Kinetix 5700 Servo Drives
Kinetix VPF Motor Performance Specifications with Kinetix 5700 Drives
Kinetix VPF Motor Performance with Kinetix 5700 (200V operation) Drives
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(240V AC Input)
VPF-A0632F 4800 4800 2.55 0.93 (8.0) 8.75 2.69 (24.0) 0.36 (0.48) 2198-D006-ERSx
VPF-A0633C 3000 3000 2.50 1.27 (11.0) 8.75 4.09 (36.0) 0.37 (0.50) 2198-D006-ERSx
VPF-A0633F 4500 4500 3.52 1.27 (11.0)
8.80 2.87 (25.0)
0.47 (0.63)
2198-D006-ERSx
12.60 4.09 (36.0) 2198-D012-ERSx
VPF-A0752C 3300 3300 3.80 1.61 (14.0) 13.30 4.39 (39.0) 0.49 (0.66) 2198-D012-ERSx
VPF-A0752E 4800 4800 4.90 1.61 (14.0)
17.70 4.10 (36.0)
0.63 (0.84)
2198-D012-ERSx
18.90 4.39 (39.0) 2198-D020-ERSx
VPF-A0753C 3300 3300 4.09 2.16 (19.0)
17.70 6.55 (58.0)
0.59 (0.79)
2198-D012-ERSx
18.90 7.02 (62.0) 2198-D020-ERSx
VPF-A0753E 4600 4600 6.12 2.28 (20.0)
17.70 5.13 (45.0)
0.76 (1.02)
2198-D012-ERSx
25.34 7.35 (65.0) 2198-D020-ERSx
VPF-A1001C 2800 2800 3.61 1.93 (17.0)
8.80 3.22 (28.0)
0.56 (0.75)
2198-D006-ERSx
10.38 3.78 (33.0) 2198-D012-ERSx
VPF-A1001M 6500 6500 7.15 1.95 (17.0)
17.70 3.31 (29.0)
1.29 (1.73)
2198-D012-ERSx
20.20 3.78 (33.0) 2198-D020-ERSx
VPF-A1002C 3000 3000 6.24 3.39 (30.0)
17.70 6.80 (60.0)
1.03 (1.38)
2198-D012-ERSx
20.33 7.82 (69.0) 2198-D020-ERSx
VPF-A1002F 5000 5000 10.04 3.26 (29.0)
28.30 6.77 (60.0)
1.60 (2.14)
2198-D020-ERSx
34.30 7.82 (69.0) 2198-D032-ERSx
VPF-A1003C 2250 2250 6.14 4.18 (37.0)
17.70 9.76 (86.0)
0.83 (1.11)
2198-D012-ERSx
20.20 11.15 (99.0) 2198-D020-ERSx
VPF-A1003E 3750 3750 9.58 4.18 (37.0)
28.30 9.76 (86.0)
1.25 (1.67)
2198-D020-ERSx
28.80 11.15 (99.0) 2198-D032-ERSx
VPF-A1003F 5500 5500 15.62 4.18 (37.0)
45.90 10.25 (90.0)
1.81 (2.42)
2198-D032-ERSx
50.0 11.15 (99.0) 2198-D057-ERSx
VPF-A1153C 2300 2300 8.88 6.50 (58.0)
28.30 18.30 (162)
1.16 (1.56)
2198-D020-ERSx
33.0 20.33 (180) 2198-D032-ERSx
VPF-A1303B 1950 1950 10.34 8.80 (78.0)
28.30 19.85 (175)
1.53 (2.05)
2198-D020-ERSx
31.0 20.72 (183) 2198-D032-ERSx
VPF-A1303F 4000 4000 18.60 7.75 (69.0)
45.90 15.36 (136)
2.25 (3.02)
2198-D032-ERSx
62.0 20.72 (183) 2198-D057-ERSx
VPF-A1304A 1600 1600 9.43 10.29 (91.0)
28.30 25.03 (221)
1.47 (1.98)
2198-D020-ERSx
33.76 28.45 (252) 2198-D032-ERSx
VPF-A1304D 3000 3000 18.40 10.20 (90.0)
45.90 21.48 (190)
1.98 (2.65)
2198-D032-ERSx
58.0 27.10 (240) 2198-D057-ERSx
