Rockwell Automation Allen-Bradley Kinetix 5700 Selection Guide

60 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 5700 Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix VPF Motor Performance Specifications with Kinetix 5700 (400V operation) Drives
Motor Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A (0-pk)
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
VPF-B0632F 4600 4600 1.20 0.93 (8.0) 4.20 2.69 (24.0) 0.34 (0.46) 2198-D006-ERSx
VPF-B0632T 8000 8000 2.55 0.93 (8.0) 8.75 2.69 (24.0) 0.41 (0.55) 2198-D006-ERSx
VPF-B0633M 6700 6700 2.50 1.27 (11.0) 8.75 4.09 (36.0) 0.49 (0.66) 2198-D006-ERSx
VPF-B0633T 8000 8000 3.52 1.27 (11.0)
8.80 2.87 (25.0)
0.48 (0.64)
2198-D006-ERSx
12.60 4.09 (36.0) 2198-D012-ERSx
VPF-B0752E 4900 4900 2.70 1.61 (14.0)
8.80 4.10 (36.0)
0.64 (0.86)
2198-D006-ERSx
9.45 4.39 (39.0) 2198-D012-ERSx
VPF-B0752F 7000 7000 3.80 1.61 (14.0) 13.30 4.39 (39.0) 0.76 (1.02) 2198-D012-ERSx
VPF-B0752M 8000 8000 4.90 1.61 (14.0)
17.60 4.10 (36.0)
0.77 (1.04)
2198-D012-ERSx
18.90 4.39 (39.0) 2198-D020-ERSx
VPF-B0753E 4500 4500 3.80 2.28 (20.0) 13.30 7.35 (65.0) 0.77 (1.04) 2198-D012-ERSx
VPF-B0753F 6600 6600 4.09 2.16 (19.0)
17.60 6.55 (58.0)
0.61 (0.82)
2198-D012-ERSx
18.90 7.02 (62.0) 2198-D020-ERSx
VPF-B0753M 8000 8000 6.12 2.28 (20.0)
17.60 5.13 (45.0)
0.78 (1.05)
2198-D012-ERSx
25.34 7.35 (65.0) 2198-D020-ERSx
VPF-B1001M 6000 6000 3.61 1.93 (17.0)
8.80 3.22 (28.0)
1.14 (1.53)
2198-D006-ERSx
10.38 3.78 (33.0) 2198-D012-ERSx
VPF-B1002E 3300 3300 3.44 3.39 (30.0)
8.80 6.47 (57.0)
1.12 (1.50)
2198-D006-ERSx
10.69 7.82 (69.0) 2198-D012-ERSx
VPF-B1002M 6000 6000 6.24 3.39 (30.0)
17.60 6.80 (60.0)
1.86 (2.49)
2198-D012-ERSx
20.33 7.82 (69.0) 2198-D020-ERSx
VPF-B1003C 2500 2500 3.41 4.18 (37.0)
8.80 9.29 (82.0)
0.91 (1.23)
2198-D006-ERSx
10.61 11.15 (99.0) 2198-D012-ERSx
VPF-B1003F 4750 4750 6.14 4.18 (37.0)
17.60 9.76 (86.0)
1.57 (2.10)
2198-D012-ERSx
20.20 11.15 (99.0) 2198-D020-ERSx
VPF-B1003T 7000 7000 9.58 4.18 (37.0)
28.20 9.76 (86.0)
1.68 (2.25)
2198-D020-ERSx
28.80 11.15 (99.0) 2198-D032-ERSx
VPF-B1153E 3200 3200 6.13 6.50 (58.0)
17.60 16.85 (149)
1.40 (1.88)
2198-D012-ERSx
21.33 20.33 (180) 2198-D020-ERSx
VPF-B1153F 5000 5000 8.88 6.50 (58.0)
28.20 18.30 (162)
1.49 (2.00)
2198-D020-ERSx
33.0 20.33 (180) 2198-D032-ERSx
VPF-B1303C 2250 2250 6.30 8.80 (78.0)
17.60 19.83 (175)
1.74 (2.33)
2198-D012-ERSx
18.47 20.72 (183) 2198-D020-ERSx
VPF-B1303F 4000 4000 10.10 8.80 (78.0)
28.20 19.85 (175)
2.54 (3.40)
2198-D020-ERSx
31.0 20.72 (183) 2198-D032-ERSx
VPF-B1304C 2150 2150 7.0 10.29 (91.0)
17.60 22.55 (199)
1.49 (2.00)
2198-D012-ERSx
22.3 28.45 (252) 2198-D020-ERSx
VPF-B1304E 3500 3500 9.44 10.29 (91.0)
28.20 25.03 (221)
2.40 (3.21)
2198-D020-ERSx
33.76 28.45 (252) 2198-D032-ERSx
VPF-B1652C 2700 2700 16.0 19.40 (172)
45.90 44.78 (396)
4.18 (5.60)
2198-D032-ERSx
49.88 48.60 (430) 2198-D057-ERSx
