72 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 5700 Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPAS Performance Specifications with Kinetix 5700 Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix VPAR Performance Specifications with Kinetix 5700 Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
LDAT-S154010-Dxx
…
LDAT-S154090-Dxx
3.5 10.7
1306 (294)
39.1
3597 (809)
3.83 2198-D032-ERSx
LDAT-S154010-Exx
…
LDAT-S154090-Exx
1.8 5.3 19.5 1.78 2198-D020-ERSx
LDAT-S156010-Dxx
…
LDAT-S156090-Dxx
3.6 16.3
1997 (449)
59.4
5469 (1229)
5.85 2198-D057-ERSx
LDAT-S156010-Exx
…
LDAT-S156090-Exx
1.8 8.1 19.8 2.71 2198-D020-ERSx
Linear Stage
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5700 Drives
(480V AC input)
MPAS-Bxxxx1-V05SxA
200 (7.9)
(1)
(1) For 900 mm stroke length, maximum speed is 176 mm/s (6.9 in/s). For 1020 mm stroke length, maximum speed is 143 mm/s (5.6 in/s).
1.75 521 (117) 3.50 1212 (272) 0.37 2198-D006-ERSx
MPAS-Bxxxx2-V20SxA
1124 (44.3)
(2)
(2) For 780 mm stroke length, maximum speed is 889 mm/s (35.0 in/s). For 900 mm stroke length, maximum speed is 715 mm/s (28.2 in/s). For 1020 mm stroke length,
maximum speed is 582 mm/s (22.9 in/s).
3.30 462 (104) 6.60 968 (218) 0.62 2198-D006-ERSx
MPAS-B8xxxF-ALMO2C 5000 (200) 3.50 189 (42.5) 9.30 456 (103) 0.527 2198-D012-ERSx
MPAS-B8xxxF-ALMS2C 5000 (200) 3.15 159 (35.7) 8.37 399 (89.7) 0.475 2198-D006-ERSx
MPAS-B9xxxL-ALMO2C 5000 (200) 3.40 285 (64.1) 9.10 680 (153) 0.768 2198-D012-ERSx
MPAS-B9xxxL-ALMS2C 5000 (200) 3.03 245 (55.1) 8.19 601 (135) 0.69 2198-D006-ERSx
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5700 Drives
(480V AC input)
VPAR-B1xxxB 150 0.41 240 (53.9) 1.34 300 (67.4) 0.11 2198-D006-ERSx
VPAR-B1xxxE 500 1.20 280 (62.9) 2.10 350 (78.7) 0.24 2198-D006-ERSx
VPAR-B2xxxC 250 1.25 420 (94.4) 2.67 525 (118) 0.25 2198-D006-ERSx
VPAR-B2xxxF 640 3.10 640 (144) 5.80 800 (180) 0.56 2198-D012-ERSx
VPAR-B3xxxE 500 5.10 2000 (450) 13.0 2500 (562) 1.30 2198-D012-ERSx
VPAR-B3xxxH 1000 8.60 1284 (289) 17.0 1625 (365) 1.68 2198-D020-ERSx
Performance Specifications with Frame 150 Linear Thrusters (continued)
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
460V AC
kW
Kinetix 5700 Drives
(480V AC input)
To Next Page
