Connected Components Platform
Connected Components Platform
Part of the Rockwell Automation Machine Solutions offering, Connected Components is a preferred control solution for machine builders who
provide standalone machines at low cost. Connected Components provides just enough control to meet machine and end-user requirements
while helping to improve operating efficiencies.
Kinetix 5100 EtherNet/IP indexing servo drives have multiple control modes to support a wide range of high-speed, low-power motion control
applications. The drive can be used with a Micro800™ controller, a Logix controller or even by itself, allowing OEMs to choose how the product
best functions in their applications. The Kinetix 5100 servo drive with Kinetix TLP motor and cable can function as a system without a
controller and provide a more cost-effective option for OEMs building smaller machines.
Select a Kinetix Motion Control System
Typical motion control systems require selections from several categories of Allen-Bradley motion control products.
MOD
NET
2
1
1
I/O-A
61
I/O-B
6
510510
UFB-A UFB-B
D+
D-
MF-A MF-B
D+
D-
MOD
NET
2
1
1
4
I/O
MOD
DC BUS
MODULE
STATUS
MOD
NET
1
I/O
6
5
10
2
1
UFB
MBRK
+
-
D+
D-
MF
2090-Series Single Motor Cables
2090-Series Motor Power/Brake
and Feedback Cables
Rotary Motion
Linear Motion
Motor Cables,
Interface Cables, and Other Drive
Accessories
Kinetix Servo Drives
(Kinetix 5700 drive system is shown)
Motor Feedback
Connector Kits
To Next Page
