Kinetix 5700 Servo Drives
Kinetix VPH (brake) Motor Performance Specifications with Kinetix 5700 (400V operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPL Motor Performance Specifications with Kinetix 5700 Drives
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
VPH-B0632T-xxx4 7200 8000 2.43 0.80 (7.1) 8.75 2.69 (24.0) 0.40 (0.54) 2198-D006-ERSx
VPH-B0633M-xxx4670067001.97 1.01 (8.9) 8.75 4.09 (36.0) 0.50 (0.67) 2198-D006-ERSx
VPH-B0753F-xxx4 6600 6600 3.49 1.81 (16.0)
8.80 3.27 (28.9)
0.68 (0.92)
2198-D006-ERSx
18.90 7.02 (62.0) 2198-D020-ERSx
VPH-B1001F-xxx4 5000 5000 2.20 1.42 (12.6) 7.10 3.61 (32.0) 0.68 (0.91) 2198-D006-ERSx
VPH-B1003F-xxx4 4750 4750 4.89 3.29 (29.1)
17.60 9.71 (86.0)
1.16 (1.56)
2198-D012-ERSx
20.20 11.15 (99.0) 2198-D020-ERSx
VPH-B1152F-xxx4 4500 4500 5.15 4.03 (35.7)
17.60 10.89 (96.4)
1.37 (1.84)
2198-D012-ERSx
21.19 13.12 (116) 2198-D020-ERSx
VPH-B1153E-xxx4 3900 5000 7.09 5.13 (45.4)
17.60 10.84 (96.0)
1.08 (1.45)
2198-D012-ERSx
33.00 20.33 (180) 2198-D032-ERSx
VPH-B1304E-xxx4350035008.27 8.24 (73.0)
28.20 23.74 (210)
1.76 (2.36)
2198-D020-ERSx
33.76 28.45 (252) 2198-D032-ERSx
VPH-B1653D-xxx4 3000 3000 14.92 18.67 (165)
45.90 45.77 (405)
2.91 (3.91)
2198-D032-ERSx
68.00 67.80 (600) 2198-D057-ERSx
Kinetix VPS Motor Performance Specifications with Kinetix 5700 Drives
Motor Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5700 Drives
(480V AC input)
VPS-B1304D 3000 3000 7.1 8.1 (72.0)
17.6 17.9 (158)
1.40 (1.9)
2198-D012-ERSx
26.0 27.1 (240) 2198-D020-ERSx
VPS-B1653D 3000 3000 17.0 21.0 (186)
45.9 50.1 (443)
3.29 (4.4)
2198-D032-ERSx
68.0 67.8 (600) 2198-D057-ERSx
Kinetix MPL Motor Performance Specifications with Kinetix 5700 (200V operation) Drives
Rotary Motor
Cat. No.
Rated Speed
rpm
Maximum Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5700
(230V AC input)
MPL-A1510V 8000 8000 1.05 0.26 (2.3) 3.40 0.77 (6.8) 0.16 2198-D006-ERSx
MPL-A1520U 7000 7000 1.80 0.49 (4.3) 6.10 1.58 (13.9) 0.27 2198-D006-ERSx
MPL-A1530U 7000 7000 2.82 0.90 (8.0) 10.1 2.82 (24.9) 0.39 2198-D012-ERSx
MPL-A210V 8000 8000 3.09 0.55 (4.8) 10.2 1.52 (13.4) 0.37 2198-D012-ERSx
MPL-A220T 6000 6000 4.54 1.61 (14.2) 15.5 4.74 (41.9) 0.62 2198-D012-ERSx
MPL-A230P 5000 5000 5.40 2.10 (18.6) 23.0 8.2 (73.0) 0.86 2198-D020-ERSx
MPL-A310F 3000 3000 3.20 1.58 (14.0)
8.80 3.44 (30.4)
0.46
2198-D006-ERSx
9.30 3.61 (31.9) 2198-D012-ERSx
MPL-A310P 5000 5000 4.85 1.58 (14.0) 14.0 3.61 (31.9) 0.73 2198-D012-ERSx
MPL-A320H 3500 3500 6.10 3.05 (27.0) 19.3 7.91 (70.0) 1.0 2198-D020-ERSx
MPL-A320P 5000 5000 9.00 3.05 (27.0)
28.3 7.60 (44.8)
1.3
2198-D020-ERSx
29.5 7.91 (70.0) 2198-D032-ERSx
MPL-A330P 5000 5000 12.0 4.18 (37.0) 38.0 11.1 (98.2) 1.8 2198-D032-ERSx
MPL-A420P 5000 5000 12.7 4.79 (42.3) 46.0 13.5 (120) 2.0 2198-D032-ERSx
MPL-A430H 3500 3500 12.2 6.21 (55.0) 45.0 19.8 (175) 1.8 2198-D032-ERSx
MPL-A430P 5000 5000 16.80 5.99 (52.9) 67.0 19.8 (175) 2.2 2198-D057-ERSx
MPL-A4530F 2800 2800 13.40 8.36 (74.0) 42.0 20.3 (179) 1.9 2198-D032-ERSx
MPL-A4530K 4000 4000 19.50 8.13 (71.9) 62.0 20.3 (179) 2.5 2198-D057-ERSx
To Next Page
