Kinetix 300 and Kinetix 350 EtherNet/IP Servo Drives
Kinetix MPF Motor Performance Specifications with Kinetix 300/350 Drives
Performance Specifications with Kinetix 300/350 (200V-class, single-phase) Drives
Performance Specifications with Kinetix 300/350 (200V-class, three-phase) Drives
Performance Specifications with Kinetix 300/350 (400V-class, three-phase) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A (0-pk)
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 300/350
200V-class
Single-phase Drives
MPF-A310P 4750 5000 4.85 1.58 (14) 14 3.61 (32) 0.73
2097-V33PR3-xx
2097-V32PR2-xx
2097-V31PR2-xx
MPF-A320H 3350 3500 6.1 3.05 (27) 19.3 7.91 (70) 1.0
2097-V33PR5-xx
2097-V32PR4-xx
MPF-A320P 4750 5000 9.0 3.05 (27) 29.5 7.91 (70) 1.3
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A (0-pk)
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 300/350
200V-class
Three-phase Drives
MPF-A310P 4750 5000 4.85 1.58 (14) 14 3.61 (32) 0.73 2097-V33PR3-xx
MPF-A320H 3350 3500 6.1 3.05 (27) 19.3 7.91 (70) 1.0 2097-V33PR5-xx
MPF-A320P 4750 5000 9.0 3.05 (27) 29.5 7.91 (70) 1.3 2097-V33PR5-xx
MPF-A330P 5000 5000 12.0 4.18 (37) 38 11.1 (98) 1.6 2097-V33PR6-xx
MPF-A430H 3500 3500 12.2 6.21 (55) 45 19.8 (175) 1.8 2097-V33PR6-xx
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A (0-pk)
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A (0-pk)
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 300/350
400V-class
Three-phase Drives
MPF-B310P 5000 5000 2.30 1.58 (14) 7.1 3.61 (32) 0.77 2097-V34PR3-
xx
MPF-B320P 5000 5000 4.24 3.05 (27) 14.0 7.34 (65) 1.5 2097-V34PR5-xx
MPF-B330P 5000 5000 5.70 4.18 (37)
16.9 10.0 (88)
1.6
2097-V34PR5-xx
19.0 11.1 (98) 2097-V34PR6-xx
