Kinetix 5700 Servo Drives
Functional Safety Configurations
Kinetix 5700 servo drives are capable of safe torque-off (STO) and safe stop 1 (SS1) drive-based safety functions via hardwired connections
or integrated over the EtherNet/IP network. In addition, safely limited speed (SLS) and other controller-based safety instructions are also
possible. These examples illustrate the functional safety configuration options.
Hardwired Safety Configuration
Kinetix 5700 servo drives use the safe torque-off (STO) connector for wiring external safety devices and cascading hardwired safety
connections from one drive to another.
Safe Torque-off (hardwired) Configuration
These example configurations use the 2198-Pxxx DC-bus power supply. However, 2198-RPxxx regenerative bus supply can be
used instead.
