64 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 5700 Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPM Motor Performance Specifications with Kinetix 5700 Drives
Kinetix MPM Motor Performance Specifications with Kinetix 5700 (200V operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
MPL-B880C 1500 1500 47.5 110 (973) 97.5 203 (1797) 12.6 2198-S086-ERSx
MPL-B880D 2000 2000 67.0 110 (973) 96.0 147 (1301) 12.6 2198-S130-ERSx
MPL-B960B 1200 1200 42.5 130 (1150) 94.0 231 (2044) 12.7 2198-S086-ERSx
MPL-B960C 1500 1500 55.0 124.3 (1100)
121.6 219.8 (1945)
14.8
2198-S086-ERSx
125 226 (2000) 2198-S130-ERSx
MPL-B960D 2000 2000 70.0 124.3 (1100) 125 226 (2000) 15.0 2198-S130-ERSx
MPL-B980B 1000 1000 40.0 162.7 (1444) 94.0 278 (2460) 15.2 2198-S086-ERSx
MPL-B980C 1500 1500 68.2 158.2 (1400) 140 271.2 (2400) 16.8 2198-S130-ERSx
MPL-B980D 2000 2000 79.0 158.2 (1400) 140 260 (2300) 18.6 2198-S130-ERSx
MPL-B980E 1500 2750 105 141 (1250)
226.2 233 (2062)
13.0
2198-S160-ERSx
230 237 (2100) 2198-S263-ERSx
Rotary Motor
Cat. No.
Base Speed
rpm
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5700 Drives
(240V AC input)
MPM-A1151M 4500 5000 6000 7.65 2.3 (20.3)
28.3 6.2 (54.9)
0.90
2198-D020-ERSx
30.5 6.6 (58.4) 2198-D032-ERSx
MPM-A1152F 3000 4000 5000
11.30 4.4 (38.9) 28.3 9.4 (83.2)
1.40
2198-D020-ERSx
11.93 4.7 (41.6) 44.8 13.5 (119) 2198-D032-ERSx
MPM-A1153F 3000 4000 5000 16.18 6.5 (57.5)
45.9 15.3 (135)
1.45
2198-D032-ERSx
64.5 19.8 (175) 2198-D057-ERSx
MPM-A1302F 3000 4000 4500 17.28 6.6 (58.4)
45.9 12.7 (112)
1.65
2198-D032-ERSx
50.2 13.5 (119) 2198-D057-ERSx
MPM-A1304F 3000 3500 4000 19.65 9.3 (82.0)
45.9 18.6 (165)
2.20
2198-D032-ERSx
48.3 19.3 (171) 2198-D057-ERSx
MPM-A1651F 3000 3000 5000 30.96 10.7 (94.7) 73.8 20.5 (181) 2.50 2198-D057-ERSx
MPM-A1652F 3000 3500 4000 33.54 13.5 (119) 103.2 36.0 (319) 4.03 2198-S086-ERS
x
MPM-A1653F 3000 3000 4000 42.4 18.6 (165) 119.1 42.0 (372) 5.10 2198-S086-ERSx
MPM-A2152F 3000 2000 4000 58.4 27.0 (239)
121.6 54.1 (479)
5.20
2198-S086-ERSx
125.8 56.0 (495) 2198-S130-ERSx
MPM-A2153F 3000 2000 3600 59.65 34.0 (301) 120.4 58.0 (513) 5.80 2198-S086-ERSx
MPM-A2154C 1500 1750 2000 58.68 55.0 (487)
121.6 101 (894)
6.50
2198-S086-ERSx
127.3 106 (938) 2198-S130-ERSx
MPM-A2154E 2250 2000 3000 59.67 44.0 (389)
121.6 79.7 (705)
7.00
2198-S086-ERSx
128.2 84.0 (743) 2198-S130-ERSx
Kinetix MPL Motor Performance Specifications with Kinetix 5700 (400V operation) Drives (continued)
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 5700 Drives
(480V AC input)
