96 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 5500 Servo Drives
Kinetix MPL Motor Performance Specifications with Kinetix 5500 Drives
These motors require the 2198-H2DCK feedback converter kit.
Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 5500 Drives
(240V AC input)
MPL-A1510V 8000 8000 1.05 0.26 (2.3) 3.40 0.77 (6.8) 0.16 2198-H003-ERSx
MPL-A1520U 7000 7000 1.80 0.49 (4.3) 6.10 1.58 (13.9) 0.27 2198-H008-ERSx
MPL-A1530U 7000 7000 2.82 0.90 (8.0) 10.1 2.82 (24.9) 0.39 2198-H015-ERSx
MPL-A210V 8000 8000 3.09 0.55 (4.8) 10.2 1.52 (13.4) 0.37 2198-H015-ERSx
MPL-A220T 6000 6000 4.54 1.61 (14.2) 15.5 4.74 (41.9) 0.62 2198-H015-ERSx
MPL-A230P 5000 5000 5.40 2.10 (18.6) 23.0 8.2 (73.0) 0.86 2198-H025-ERSx
MPL-A310F 3000 3000 3.24 1.58 (14.0)
8.80 3.44 (30.4)
0.46
2198-H008-ERSx
9.30 3.61 (31.9) 2198-H015-ERSx
MPL-A310P 5000 5000 4.91 1.58 (14.0) 14.0 3.61 (31.9) 0.73 2198-H015-ERSx
MPL-A320H 3500 3500 6.10 3.05 (27.0) 19.3 7.91 (70.0) 1.0 2198-H025-ERSx
MPL-A320P 5000 5000 9.00 3.05 (27.0)
28.3 7.60 (44.8)
1.3
2198-H025-ERSx
29.5 7.91 (70.0) 2198-H040-ERSx
MPL-A330P 5000 5000 12.0 4.18 (37.0) 38.0 11.1 (98.2) 1.8 2198-H040-ERSx
MPL-A420P 5000 5000 12.9 4.79 (42.3) 46.0 13.6 (119) 2.0 2198-H040-ERSx
MPL-A430H 3500 3500 12.2 6.21 (55.0) 45.0 19.8 (175) 1.8 2198-H040-ERSx
MPL-A430P 5000 5000 16.80 5.99 (52.9) 67.0 19.8 (175) 2.2 2198-H070-ERSx
MPL-A4530F 2800 2800 13.40 8.36 (74.0) 42.0 20.3 (179) 1.9 2198-H040-ERSx
MPL-A4530K 4000 4000 19.50 8.13 (71.9) 62.0 20.3 (179) 2.5 2198-H070-ERSx
MPL-A4540C 1500 1500 9.55 10.30 (91.1)
28.3 26.23 (232)
1.5
2198-H025-ERSx
29.0 27.1 (239) 2198-H040-ERSx
MPL-A4540F 3000 3000 18.40 10.19 (90.1)
45.9 22.09 (195)
2.6
2198-H040-ERSx
58.0 27.1 (239) 2198-H070-ERSx
MPL-A4560F 3000 3000 22.0 14.1 (125) 66.0 34.4 (305) 3.0 2198-H070-ERSx
MPL-A520K 4000 4000 15.0 10.77 (95.2) 65.0 24.2 (214) 3.5 2198-H070-ERSx
Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 5500 Drives
(480V AC input)
MPL-B1510V 8000 8000 0.95 0.26 (2.3) 3.10 0.77 (6.8) 0.16 2198-H003-ERSx
MPL-B1520U 7000 7000 1.80 0.49 (4.3) 6.10 1.58 (13.9) 0.27 2198-H008-ERSx
MPL-B1530U 7000 7000 2.0 0.90 (8.0) 7.20 2.82 (24.9) 0.39 2198-H008-ERSx
MPL-B210V 8000 8000 1.75 0.55 (4.9) 5.80 1.52 (13.4) 0.37 2198-H008-ERSx
MPL-B220T 6000 6000 3.30 1.61 (14.2)
8.80 3.67 (32.5)
0.62
2198-H008-ERSx
11.3 4.74 (41.9) 2198-H015-ERSx
MPL-B230P 5000 5000 2.60 2.10 (18.6)
8.80 6.39 (56.6)
0.86
2198-H008-ERSx
11.3 8.20 (73.0) 2198-H015-ERSx
MPL-B310P 5000 5000 2.4 1.6 (14.1) 7.10 3.6 (32) 0.77 2198-H008-ERSx
MPL-B320P 5000 5000 4.5 3.10 (27) 14.0 8.2 (72.5) 1.5 2198-H015-ERSx
MPL-B330P 5000 5000 6.1 4.18 (37)
17.7 10.4 (92.0)
1.8
2198-H015-ERSx
19.0 11.1 (98) 2198-H025-ERSx
MPL-B420P 5000 5000 6.3 4.74 (42)
17.7 11.3 (100)
1.9
2198-H015-ERSx
22.0 13.5 (119) 2198-H025-ERSx
MPL-B430P 5000 5000 9.2 6.55 (58)
28.3 17.6 (156)
2.2
2198-H025-ERSx
32.0 19.8 (175) 2198-H040-ERSx
MPL-B4530F 3000 3000 6.7 8.36 (74)
17.7 17.7 (157)
2.1
2198-H015-ERSx
21.0 20.3 (180) 2198-H025-ERSx
