Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 97
Kinetix 5500 Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Kinetix MPM Motor Performance Specifications with Kinetix 5500 Drives
These motors require the 2198-H2DCK feedback converter kit.
Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
MPL-B4530K 4000 4000 9.9 8.25 (73)
28.3 18.7 (166)
2.6
2198-H025-ERSx
31.0 20.3 (179) 2198-H040-ERSx
MPL-B4540F 3000 3000 9.1 10.20 (90)
28.3 26.2 (232)
2.6
2198-H025-ERSx
29.0 27.1 (240) 2198-H040-ERSx
MPL-B4560F 3000 3000
11.3 13.85 (123) 28.3 28.4 (251)
3.2
2198-H025-ERSx
11.8 14.0 (124) 36.0 34.4 (304) 2198-H040-ERSx
MPL-B520K 3500 4000
11.3 10.4 (92) 28.3 20.6 (182)
3.5
2198-H025-ERSx
11.5 10.7 (95) 33.0 23.2 (205) 2198-H040-ERSx
MPL-B540D 2000 2000 10.5 19.4 (172) 23.0 41.0 (362) 3.4 2198-H025-ERSx
MPL-B540K 4000 4000 20.4 19.4 (171) 60.0 48.6 (430) 5.4 2198-H070-ERSx
MPL-B560F 3000 3000 20.6 26.8 (237) 68.0 67.8 (600) 5.5 2198-H070-ERSx
MPL-B580F 3000 3000 26.0 34.0 (300) 81.3 78.9 (698) 7.1 2198-H070-ERSx
MPL-B580J 3800 3800 32.0 34.0 (301) 81.3 71.52 (633) 7.9 2198-H070-ERSx
MPL-B640F 2000 3000 32.0 36.7 (325) 65.0 72.3 (640) 6.1 2198-H070-ERSx
Motor Cat. No.
Base Speed
rpm
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5500 Drives
(240V AC input)
MPM-A1151M 4500 5000 6000 7.65 2.3 (20.3)
28.3 6.2 (54.9)
0.90
2198-H025-ERSx
30.5 6.6 (58.4) 2198-H040-ERSx
MPM-A1152F 3000 4000 5000
11.30 4.4 (38.9) 28.3 9.4 (83.2)
1.40
2198-H025-ERSx
11.93 4.7 (41.6) 44.8 13.5 (119) 2198-H040-ERSx
MPM-A1153F 3000 4000 5000 16.18 6.5 (57.5)
45.9 15.3 (135)
1.45
2198-H040-ERSx
64.5 19.8 (175) 2198-H070-ERSx
MPM-A1302F 3000 4000 4500 17.28 6.6 (58.4)
45.9 12.7 (112)
1.65
2198-H040-ERSx
50.2 13.5 (119) 2198-H070-ERSx
MPM-A1304F 3000 3500 4000 19.65 9.3 (82.0)
45.9 18.6 (165)
2.20
2198-H040-ERSx
48.3 19.3 (171) 2198-H070-ERSx
MPM-A1651F 3000 3000 5000 30.96 10.7 (94.7) 73.8 20.5 (181) 2.50 2198-H070-ERSx
Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Motor Cat. No.
Speed, base
rpm
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5500 Drives
(480V AC input)
MPM-B1151F 3000 4000 5000 2.71 2.3 (20.3)
8.8 6.0 (53.1)
0.75
2198-H008-ERSx
9.9 6.6 (58.0) 2198-H015-ERSx
MPM-B1151T 6000 5000 7000 5.62 2.3 (20.3)
17.7 5.3 (46.9)
0.90
2198-H015-ERSx
20.5 5.9 (52.2) 2198-H025-ERSx
MPM-B1152C 1500 2500 3000 3.61 5.0 (44.2) 12.4 13.5 (119) 1.20 2198-H015-ERSx
MPM-B1152F 3000 4000 5200 6.17 5.0 (44.2)
17.7 11.7 (103)
1.40
2198-H015-ERSx
21.1 13.5 (119) 2198-H025-ERSx
MPM-B1152T 6000 4000 7000 11.02 5.0 (44.2)
28.3 10.7 (94.7)
1.40
2198-H025-ERSx
37.9 13.5 (119) 2198-H040-ERSx
MPM-B1153E 2250 3000 3500 6.21 6.5 (57.5)
17.7 16.9 (149)
1.40
2198-H015-ERSx
21.6 19.8 (175) 2198-H025-ERSx
Performance Specifications with Kinetix 5500 (400V-class operation) Drives (continued)
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 5500 Drives
(480V AC input)
