Kinetix 5700 Servo Drives
Kinetix MPAR Performance Specifications with Kinetix 5700 Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
LDC-Series Performance Specifications with Kinetix 5700 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient temperature, and
rated line voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Electric Cylinder
Cat. No.
Maximum Speed
mm/s (in/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5700 Drives
(480V AC input)
MPAR-B1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036 2198-D006-ERSx
MPAR-B1xxxE 500 1.49 280 (62.9) 1.71 350 (78.7) 0.140 2198-D006-ERSx
MPAR-B2xxxC 250 1.67 420 (94.4) 1.90 525 (118) 0.105 2198-D006-ERSx
MPAR-B2xxxF 640 3.29 640 (144) 3.93 800 (180) 0.410 2198-D006-ERSx
MPAR-B3xxxE 500 5.16 2000 (450) 6.17 2500 (562) 1.00 2198-D012-ERSx
MPAR-B3xxxH 1000 6.13 1300 (292) 6.79 1625 (365) 1.30 2198-D012-ERSx
Linear Motor
Cat. No.
Maximum Speed
m/s (ft/s)
System Continuous
Stall Current
(1)
A 0-pk
(1) Values represent the range between no cooling (low value) and water cooling (high value).
System Continuous
Stall Force
(1)
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Linear Motor
Rated Output
kW
Kinetix 5700 Drives
(480V AC input)
LDC-C030100-DHT
10.0 (32.8)
4.1…6.1 74…111 (17…25) 12.1 188 (42) 0.37…0.55 2198-D012-ERSx
LDC-C030200-DHT 8.1…12.2
148…222 (33…50)
24.3
375 (84) 0.74…1.11
2198-D020-ERSx
LDC-C030200-EHT 4.1…6.1 12.1 2198-D012-ERSx
LDC-C050100-DHT
10.0 (32.8)
3.9…5.9 119…179 (27…40) 11.7 302 (68) 0.59…0.89 2198-D012-ERSx
LDC-C050200-DHT 7.9…11.8
240…359 (54…81)
23.3
600 (135) 1.20…1.79
2198-D020-ERSx
LDC-C050200-EHT 3.9…5.9 11.6 2198-D012-ERSx
LDC-C050300-DHT 11.8…17.7
363…544 (82…122)
35.9
941 (212) 1.81…2.72
2198-D032-ERSx
LDC-C050300-EHT 3.9…5.9 12.0 2198-D012-ERSx
LDC-C075200-DHT
10.0 (32.8)
7.7…11.5
348…523 (78…117)
22.9
882 (198) 1.74…2.61
2198-D020-ERSx
LDC-C075200-EHT 3.8…5.7 11.5 2198-D012-ERSx
LDC-C075300-DHT 11.5…17.2
523…784 (117…176)
35.6
1368 (308) 2.61…3.92
2198-D032-ERSx
LDC-C075300-EHT 3.8…5.7 11.9 2198-D012-ERSx
LDC-C075400-DHT 15.3…23.0
697…1045 (157…235)
47.4
1824 (410) 3.48…5.22
2198-D032-ERSx
LDC-C075400-EHT 7.7…11.5 23.7 2198-D020-ERSx
LDC-C100300-DHT
10.0 (32.8)
11.1…16.7
674…1012 (152…227)
34.3
1767 (397) 3.37…5.06
2198-D032-ERSx
LDC-C100300-EHT 3.7…5.6 11.4 2198-D012-ERSx
LDC-C100400-DHT 14.8…22.2
899…1349 (202…303)
45.7
2356 (530) 4.49…6.74
2198-D032-ERSx
LDC-C100400-EHT 7.4…11.1 22.8 2198-D020-ERSx
LDC-C100600-DHT 22.2…33.3
1349…2023 (303…455)
68.5
3534 (794) 6.74…10.11
2198-D057-ERSx
LDC-C100600-EHT 11.1…16.7 34.3 2198-D032-ERSx
LDC-C150400-DHT
10.0 (32.8)
14.1…21.1
1281…1922 (288…432)
45.2
3498 (786) 6.40…9.61
2198-D032-ERSx
LDC-C150400-EHT 7.0…10.6 22.6 2198-D020-ERSx
LDC-C150600-DHT 21.1…31.7
1922…2882 (432…648)
67.8
5246 (1179) 9.61…14.41
2198-D057-ERSx
LDC-C150600-EHT 10.6…15.8 33.9 2198-D032-ERSx
